Genesis G70 I facelift (2020-2024) passenger seat cooler switch Wiring diagram

This page shows the only wiring diagram for the component.passenger seat cooler switch, which is found in the car Genesis G70 I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram passenger seat cooler switch (1 of 1)

Wiring diagram passenger seat cooler switch for Genesis G70 I facelift (2020-2024)

Get access

A/C SWITCH BLK WIRE BLK/ORG WIRE BRN WIRE BRN/ORG WIRE COMPUTER DATA LINES SYSTEM DRIVER SEAT COOLER SWITCH DRIVER SEAT WARMER SWITCH GROUND DISTRIBUTION SYSTEM GRY WIRE ILL INPUT LEFT FRONT AIR VENTILATION SEAT BLOWER MOTOR LIN NCA WIRE ON/START PASSENGER SEAT COOLER SWITCH PASSENGER SEAT WARMER SWITCH PNK WIRE RED WIRE RED/ORG WIRE RIGHT FRONT AIR VENTILATION SEAT BLOWER MOTOR YEL WIRE

Go to component: -> Seat ventilation circuit (2 of 2) -> PASSENGER SEAT COOLER SWITCH
