Genesis G70 I facelift (2020-2024) pass walk in reclining mtr sw bwd pass reclining limit sw fwd Wiring diagram

ADJUSTER MTR DN BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE GND PASS SEAT M/RECLINING SW FWD GRN WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-A MEMORY POWER MEMORY POWER PASS FRONT HEIGHT MEMORY PWR ORG/ WIRE ORG/BLK WIRE P/SEAT PASS FUSE PASS FRONT HEIGHT ADJUSTER MTR UP PASS LUMBAR SUPPORT MTR BWD PASS LUMBAR SUPPORT MTR DN PASS LUMBAR SUPPORT MTR FWD PASS LUMBAR SUPPORT MTR UP PASS REAR HEIGHT ADJUSTER MTR DN PASS REAR HEIGHT ADJUSTER MTR UP PASS RECLINING LIMIT SW BWD PASS RECLINING MTR BWD PASS RECLINING MTR FWD PASS SEAT M/RECLINING SW BWD PASS SEAT M/SLIDE SW BWD PASS SEAT M/SLIDE SW FWD PASS SLIDE MTR BWD PASS SLIDE MTR FWD PASS WALK IN RECLINING MTR SW BWD PASS RECLINING LIMIT SW FWD PASS WALK IN RECLINING MTR SW FWD PASS WALK IN RECLINING SW BWD PASS WALK IN RECLINING SW FWD PASS WALK IN SLIDE SW BWD PASS WALK IN SLIDE SW FWD PASSENGER FRONT HEIGHT ADJUSTER MOTOR PASSENGER LUMBAR SUPPORT MOTOR (FWD/BWD) PASSENGER LUMBAR SUPPORT MOTOR (UP/DN) PASSENGER REAR HEIGHT ADJUSTER MOTOR PASSENGER RECLINING LIMIT SWITCH PASSENGER RECLINING MOTOR PASSENGER SEAT MANUAL SWITCH PASSENGER SLIDE MOTOR PASSENGER WALK IN RELAY MODULE (UNDER PASSENGER'S SEAT) PASSENGER WALK IN SWITCH PNK WIRE PNK/BLK WIRE RECLINING MTR RED WIRE RED/BLK WIRE RED/ORG WIRE SLIDE LIMIT SW BWD SLIDE LIMIT SW FWD SLIDE MTR SW BWD SW FWD WHT WIRE WHT/BLK WIRE WHT/ORG WIRE YEL/ORG WIRE
