Genesis G70 I facelift (2020-2024) parking switch Wiring diagram
This page shows the only wiring diagram for the component.parking switch, which is found in the car Genesis G70 I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram parking switch (1 of 1)
2.0L TURBO
3.3L TURBO
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
E/R JUNCTION BLOCK
E/R-D
E/R-E
FRONT WASHER SWITCH
FRONT WIPER (LOW) RELAY
FRONT WIPER HIGH RELAY
FRONT WIPER LOW BACKUP SIG
GND (BCM)
GRN WIRE
HOT AT ALL TIMES
INT/VOL SW SIG
MIST
MULTI- FUNCTION SWITCH
ON INPUT
ORG/ WIRE
PARKING SWITCH
PCB BLOCK
POSITION
RED WIRE
RIGHT END OF DASH)
VOL 1 (FAST)
VOL 2
VOL 3
VOL 4
VOL 5 (SLOW)
WASHER MOTOR SW POWER
WHT WIRE
WIPER 'P'
WIPER 1 FUSE
WIPER 2 FUSE
WIPER LOW SWITCH
WIPER MOTOR
WIPER POWER RELAY
WIPER SW SIG
YEL WIRE
Go to component: -> Front wiper/washer circuit (2 of 2) -> PARKING SWITCH
