Genesis G70 I facelift (2020-2024) parking distance warning reverse pwr Wiring diagram
This page shows the only wiring diagram for the component.parking distance warning reverse pwr, which is found in the car Genesis G70 I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram parking distance warning reverse pwr (1 of 1)
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU/ORG WIRE
BRN WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRN/ORG WIRE
GROUND DISTRIBUTION SYSTEM
GRY/BLK WIRE
IBU
ICU JUNCTION BLOCK
ICU-F
LEFT FORWARD PARKING DISTANCE WARNING
LEFT FORWARD PARKING DISTANCE WARNING (CENTER)
LIN
LIN PDW
MODULE 7 FUSE
ORG/ WIRE
PARKING DISTANCE WARNING FORWARD PWR
PARKING DISTANCE WARNING REVERSE PWR
PDW-F GND
PDW-F/R IND O/P
PDW-F/R SW I/P
POWER DISTRIBUTION SYSTEM
PWR
RED WIRE
RED/ORG WIRE
RELAY ENERGIZED
RIGHT FORWARD PARKING DISTANCE WARNING
RIGHT FORWARD PARKING DISTANCE WARNING (CENTER)
WHT WIRE
YEL WIRE
Go to component: -> Parking assistant circuit (1 of 2) -> PARKING DISTANCE WARNING REVERSE PWR
