Genesis G70 I facelift (2020-2024) memory power output Wiring diagram
This page shows the only wiring diagram for the component.memory power output, which is found in the car Genesis G70 I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram memory power output (1 of 1)
BLK WIRE
BLU/ORG WIRE
BRN/ORG WIRE
C-CAN HIGH
C-CAN LOW
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRN/ORG WIRE
HEAD-UP DISPLAY
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-F
LDC B+ INPUT
LEAK CURRENT AUTOCUT DEVICE
LOW DC-DC CONVERTER (AUDIO)
M-CAN HIGH
M-CAN LOW
MEMORY 1 FUSE
MEMORY POWER INPUT
MEMORY POWER OUTPUT
MEMORY PWR
MULTI MEDIA 1 FUSE
MULTI MEDIA 3 FUSE
ON/START INPUT
ORG/ WIRE
RED WIRE
RED/BLK WIRE
RELAY ENERGIZED
WHT/ORG WIRE
Go to component: -> Head-up display circuit -> MEMORY POWER OUTPUT
