Genesis G70 I facelift (2020-2024) heater pad Wiring diagram
This page shows the only wiring diagram for the component.heater pad, which is found in the car Genesis G70 I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram heater pad (1 of 1)
A/C SWITCH
B+1 FUSE
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
CLOCKSPRING
GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
HEATED STEERING WHEEL SWITCH
HEATER PAD
HOT AT ALL TIMES
HTD(-)
ICU JUNCTION BLOCK
ICU-B
ICU-F
ICU-G
ILL
IPS 10
IPS 10 CTRL
IPS CONTROL MODULE
NCA WIRE
NTC-
ORG/ WIRE
REAR SUB JUNCTION BLOCK
RED WIRE
RS-B
STEERING WHEEL HEATED MODULE
STEERING WHEEL HEATER NTC (-)
STEERING WHEEL HEATER SW
STEERING WHEEL HEATER SW HIGH
STEERING WHEEL HEATER SW LOW
STEERING WHEEL)
WHT WIRE
Go to component: -> Heated steering wheel circuit -> HEATER PAD
