Genesis G70 I facelift (2020-2024) engine compt) (lower left front of Wiring diagram
This page shows the only wiring diagram for the component.engine compt) (lower left front of, which is found in the car Genesis G70 I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine compt) (lower left front of (1 of 1)
2.0L TURBO
3.3L TURBO
??? ???
A/V, NAVIGATION HEAD UNIT
BLK WIRE
BLK/ORG WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
BRN/ORG WIRE
C-CAN HIGH
C-CAN LOW
C-CAN TRANSCEIVER
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
ENGINE COMPT) (LOWER LEFT FRONT OF
ETC MOTOR, THROTTLE POSITION SENSOR
GRN WIRE
GRN/BLK WIRE
HOT W/
ICU JUNCTION BLOCK
ICU-C
ICU-F
INSTRUMENT CLUSTER
LOCAL CAN HIGH
LOCAL CAN LOW
LOW SPEED OUT
MODULE 7 FUSE
MOTOR
MULTI-FUNCTION CAMERA UNIT
ON/START INPUT
ORG/ WIRE
ORG/BLK WIRE
PNK/BLK WIRE
RED WIRE
RED/BLK WIRE
SIG 3 GND
SMART CRUISE CONTROL MODULE
SPEEDOMETER
SUNROOF ASSEMBLY
SUNROOF CONTROL UNIT (GLASS)
TACHOMETER
THROTTLE POSITION SENSOR
TRIP
TRIP SW(-)
WHT WIRE
YEL WIRE
Go to component: -> Cruise control circuit (2 of 3) -> ENGINE COMPT) (LOWER LEFT FRONT OF
