Genesis G70 I facelift (2020-2024) electronic oil pump module Wiring diagram
This page shows the only wiring diagram for the component.electronic oil pump module, which is found in the car Genesis G70 I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electronic oil pump module (1 of 1)
2.0L TURBO
3.3L TURBO
BLK WIRE
BLK/ORG WIRE
BLOWER RELAY
E/R JUNCTION BLOCK
E/R JUNCTION BLOCK POWER OUTLET RELAY
E/R-B
E/R-E
ELECTRONIC OIL PUMP MODULE
ELECTRONIC VACUUM PUMP
FRONT WIPER (LOW) RELAY
FRONT WIPER HIGH RELAY
FUEL FILLER ACTUATOR
FUEL PUMP CONTROL MODULE
FUEL PUMP CONTROL MODULE SHIELD
FUEL SENDER, FUEL PUMP MOTOR
GRN WIRE
GRY WIRE
HOOD SWITCH
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
LEFT ACTIVE AIR FLAP
LEFT BLIND-SPOT COLLISION WARNING UNIT
LEFT HEADLAMP
LEFT HORN
LEFT REAR COMBINATION LAMP (OUT)
LEFT VARIABLE EXHAUST FLAP ACTUATOR
M/T
NCA WIRE
NEUTRAL SWITCH
POWER TRUNK LID PUSH BUTTON
POWER TRUNK MODULE BUZZER
REAR VIEW CAMERA
RIGHT ACTIVE AIR FLAP
RIGHT HEADLAMP
RIGHT HORN
SUNROOF CONTROL UNIT (GLASS)
SUNROOF CONTROL UNIT (ROLLER)
TCM
TRANSMISSION PARK POSITION SENSOR/SWITCH
TRUNK LID LATCH
W/ ISG
W/ LED
W/ SVM
W/O SVM
WASHER LEVEL SENSOR
WASHER MOTOR
WHT WIRE
Go to component: -> Ground distribution circuit (3 of 6) -> ELECTRONIC OIL PUMP MODULE
