Genesis G70 I facelift (2020-2024) brake booster vacuum pressure sensor Wiring diagram
This page shows the only wiring diagram for the component.brake booster vacuum pressure sensor, which is found in the car Genesis G70 I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake booster vacuum pressure sensor (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRAKE BOOSTER VACUUM PRESSURE SENSOR
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
CMPS (EXHAUST) GND
CONSOLE SWITCH
CRASH PAD SWITCH
ECTS (SIGNAL) MAP SENSOR 2 SIG
ENGINE COOLANT TEMPERATURE SENSOR
EWGA DC MTR OUTPUT (+)
EWGA SENS GND
EWGA SENSOR
FUEL RAIL PRESSURE SENSOR
FUEL RAIL SNSR GND
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
ICU JUNCTION BLOCK
ICU-E
IGN COIL CTRL CYL 1
IGN COIL CTRL CYL 2
IGN COIL CTRL CYL 3
IGN COIL CTRL CYL 4
ILL
INTAKE TEMPERATURE SENSOR
ISG OFF SW IND
ISG OFF SW SIG
ISG OFF SWITCH
MODULE 7 FUSE
OIL TEMP SENSOR SIG
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/ORG WIRE
RELAY ENERGIZED
SENS GND
SENS SIG
VCM DC MTR OUTPUT (-)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/ORG WIRE
Go to component: -> Wiring diagram engine performance 2.0l turbo, engine controls circuit (1 of 7) -> BRAKE BOOSTER VACUUM PRESSURE SENSOR
