Genesis G70 I facelift (2020-2024) auto light sens sply Wiring diagram
This page shows the only wiring diagram for the component.auto light sens sply, which is found in the car Genesis G70 I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto light sens sply (1 of 1)
AUTO LIGHT SENS GND
AUTO LIGHT SENS SIG
AUTO LIGHT SENS SPLY
AUTO LIGHT SENSOR
AUTO LIGHT, PHOTO SENSOR
B-CAN HIGH
B-CAN LOW
BACKUP SW OUT
BLK WIRE
BLU/ORG WIRE
BRN WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DIMMER SWITCH
GND (BCM)
GRY WIRE
HEADLAMP
HEADLAMP HIGH SW IN
HEADLAMP LOW
HEADLAMP SWITCH
HIGH SW OUT
HOT AT ALL TIMES
IBU (RIGHT SIDE OF DASH)
IBU 4 FUSE
ICU JUNCTION BLOCK
ICU-F
LEAK CURRENT AUTOCUT DEVICE
LIGHT
LIGHT SW SIG
MULTI- FUNCTION SWITCH
OFF SWITCH
OUTSIDE MIRROR (B+)
PASSING SWITCH
POWER DISTRIBUTION SYSTEM
PWR GND
RED WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
SW OUT
TAIL SWITCH
W/O RAIN SENSOR
WHT WIRE
WIPER, LIGHT GND
Go to component: -> Headlights circuit (1 of 3) -> AUTO LIGHT SENS SPLY
