Genesis G70 I facelift (2020-2024) auto defogger actuator f/b Wiring diagrams

A/C 1 FUSE A/C CONTROL MODULE AMBIENT TEMP SENS (+) AUTO DEFOGGER ACTUATOR AUTO DEFOGGER ACTUATOR CLOSE AUTO DEFOGGER ACTUATOR F/B AUTO DEFOGGER ACTUATOR OPEN BLK WIRE BLK/ORG WIRE BLOWER FUSE BLOWER MOTOR BLOWER RELAY BLU WIRE BLU/ORG WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CONSOLE ON/OFF ACTUATOR CONSOLE ON/OFF ACTUATOR F/B CONSOLE ON/OFF ACTUATOR OFF CONSOLE ON/OFF ACTUATOR ON CONSOLE TEMP ACTUATOR COOL CONSOLE TEMP ACTUATOR WARM DRIVER TEMP ACTUATOR COOL DRIVER TEMP ACTUATOR F/B DRIVER TEMP ACTUATOR WARM E/R JUNCTION BLOCK EVAPORATOR SENS (+) FET (FIELD EFFECT TRANSISTOR) GRN WIRE GRY WIRE GRY/BRN WIRE HOT AT ALL TIMES HUMIDITY (PWM) INCAR SENSOR INTAKE ACTUATOR F/B INTAKE ACTUATOR FRE INTAKE ACTUATOR REC LH PHOTO SENSOR (-) MODE ACTUATOR (LEFT SIDE OF HVAC UNIT) MODE ACTUATOR DEF MODE ACTUATOR F/B MODE ACTUATOR VENT MULTI FUSE 1 NCA WIRE ORG/ WIRE P-CAN HIGH P-CAN LOW PASSENGER TEMP ACTUATOR COOL PASSENGER TEMP ACTUATOR F/B PASSENGER TEMP ACTUATOR WARM PNK WIRE PNK/BLK WIRE RED WIRE RH PHOTO SENSOR (-) CONSOLE TEMP ACTUATOR F/B RIGHT END OF DASH) WHT WIRE YEL WIRE YEL/BLK WIRE

A/C CONTROL MODULE A/C SWITCH AUTO DEFOGGER ACTUATOR AUTO DEFOGGER ACTUATOR CLOSE AUTO DEFOGGER ACTUATOR F/B AUTO DEFOGGER ACTUATOR OPEN AUTO DEFOGGER SENSOR BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DEFOGGER DRIVER POWER OUTSIDE MIRROR GRN WIRE GRY WIRE HEATED MIRROR FUSE HOT AT ALL TIMES HUMIDITY (PWM) I/P-D I/P-G ICU JUNCTION BLOCK IND IPS CONTROL MODULE LSD MODULE 5 FUSE NCA WIRE OFF ON/START INPUT ORG/ WIRE ORG/BLK WIRE P-CAN P-CAN HIGH P-CAN LOW PASSENGER POWER OUTSIDE MIRROR PNK WIRE PNK/BLK WIRE REAR DEFOGGER REAR DEFOGGER RELAY CONTROL REAR DEFOGGER SWITCH REAR DEFOGGER SWITCH INPUT REAR HEATED FUSE REAR HEATED RELAY REAR SUB JUNCTION BLOCK RED WIRE RELAY ENERGIZED RS-B SENSOR GND SENSOR SUPPLY WHT WIRE YEL WIRE
