Genesis G70 I (2017-2021) overhead console switch Wiring diagram
This page shows the only wiring diagram for the component.overhead console switch, which is found in the car Genesis G70 I (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram overhead console switch (1 of 1)
A/BAG IND FUSE
ACTIVE AIR FLAP MODULE
AIR BAG FUSE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
CONSOLE SWITCH
CRASH PAD SWITCH
DATA LINK CONNECTOR
E-SHIFTER 1 FUSE
ECS UNIT
ELECTRONIC ATM SHIFT LEVER
FROM MULTI FUSE 2 (DIAGRAM 2 OF 10)
FROM REAR SUB JUNCTION BLOCK (DIAGRAM 3 OF 10)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/ORG WIRE
HAZARD SWITCH
I/P-A
I/P-C
I/P-D
I/P-E
I/P-F
IBU
INSTRUMENT CLUSTER
IPS 1
IPS 1 CONTROL
IPS 2
IPS 2 CONTROL
IPS 4
IPS 4 CONTROL
IPS CONTROL MODULE
LEFT BLIND-SPOT COLLISION WARNING UNIT
LEFT DRL LAMP
LEFT HEADLAMP
LEFT LICENSE LAMP
LEFT REAR COMBINATION LAMP (OUT)
LEFT TURN SIGNAL LAMP
M/T A/T
MODULE 1 FUSE
MODULE 7 FUSE
MULTI-FUNCTION CAMERA UNIT
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
OVERHEAD CONSOLE SWITCH
PASSENGER OCCUPANT DETECTION SENSOR
PNK WIRE
RED WIRE
RIGHT BLIND-SPOT COLLISION WARNING UNIT
RIGHT DRL LAMP
RIGHT HEADLAMP
RIGHT LICENSE LAMP
RIGHT REAR COMBINATION LAMP (OUT)
RIGHT TURN SIGNAL LAMP
SMART CRUISE CONTROL MODULE
SRS CONTROL MODULE
STEERING ANGLE SENSOR
STEERING TILT, TELESCOPIC MODULE
TO MODULE 5 FUSE (DIAGRAM 5 OF 10)
W/ BCW
W/ LED
W/O BCW
W/O LED
W/O LED W/ LED
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Power distribution circuit (4 of 10) -> OVERHEAD CONSOLE SWITCH
