Genesis G70 I (2017-2021) oil pressure sw in Wiring diagram
This page shows the only wiring diagram for the component.oil pressure sw in, which is found in the car Genesis G70 I (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram oil pressure sw in (1 of 1)
2.0L TURBO
3.3L TURBO
AIR BAG (+) IN
AIR BAG IND
AMP
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SENSOR
BRN WIRE
BRN/WHT WIRE
C-CAN TRANSCEIVER
CONVENTIONAL SUPERVISION
DAC
DETENT OUT
DRIVE MODE SW CCW IN
DRIVE MODE SW CW IN
FOOT PARKING BRAKE SWITCH
FROM PIN 39 (DIAGRAM 1 OF 3)
FROM PIN 40 (DIAGRAM 1 OF 3)
FUEL
FUEL GAUGE
FUEL SENDER
FUEL SENDER, FUEL PUMP MOTOR
FUEL SUB SENDER
FUEL TANK
GRY WIRE
HAND PARKING BRAKE SWITCH
ILL (-) OUT
INSTRUMENT CLUSTER
LEVEL SENDER 1
LEVEL SENDER 2
M-CAN TRANSCEIVER
MICOM
N (M/T) IN
NCA WIRE
OIL PRESSURE SW IN
OIL PRESSURE SWITCH
ORG/ WIRE
PNK WIRE
SENDER
SIG 1 GND
SIG 3 GND
SPEAKER IN (-)
SPEAKER OUT -
SPEED OUT
SPEEDOMETER
TACHOMETER
TEMPERATURE GAUGE
W/ FOOT BRAKE
W/ HAND BRAKE
Go to component -> Instrument cluster circuit (3 of 3) -> OIL PRESSURE SW IN
