Wiring Diagrams for Genesis G70 I (2017-2021)

Automatic a/c circuit

Anti-lock brakes circuit, w/ epb Anti-lock brakes circuit, w/o epb

Forced entry circuit Immobilizer circuit

Integrated control unit circuit Ips control module circuit

Computer data lines circuit

Cooling fan circuit

Cruise control circuit

Defoggers circuit

Electronic power steering circuit Power tilt steering column circuit

Electronic suspension circuit

Wiring diagram engine performance 2.0l turbo, electric oil pump circuit Wiring diagram engine performance 2.0l turbo, engine controls circuit

Wiring diagram engine performance 3.3l turbo, electric oil pump circuit Wiring diagram engine performance 3.3l turbo, engine controls circuit

Backup lamps circuit Exterior lamps circuit

Ground distribution circuit

Adaptive front lighting circuit Headlamps circuit Headlamps leveling circuit

Horn circuit

Head-up display circuit Instrument cluster circuit

Courtesy lamps circuit Instrument illumination circuit

Memory mirrors circuit Memory power tilt & power telescopic circuit Memory seat circuit, w/ air cell lumbar support Memory seat circuit, w/o air cell lumbar support

Blind spot information system circuit Lane departure warning circuit Navigation circuit, w/ mobis amplifier Navigation circuit, w/o amplifier Navigation circuit, w/ premium amplifier Parking assistant circuit Rear view camera circuit Surround view monitor circuit

Power distribution circuit

Power door locks circuit

Electrochromic mirror circuit Power mirror circuit

Driver power seat circuit, w/o ims Front heated seats circuit Heated steering wheel circuit Passenger power seat circuit, w/o walk in Passenger power seat circuit, w/ walk in Rear heated seats circuit Seat ventilation circuit

Power top/sunroof circuit

Power windows circuit

Radio circuit, w/ mobis amplifier Radio circuit, w/o amplifier Radio circuit, w/ premium amplifier

Charging circuit Starting circuit

Supplemental restraints circuit

4wd circuit A/t circuit

Trunk & fuel door release circuit

Chime circuit Tire pressure monitoring circuit

Wiper/washer circuit

ANTI- LOCK ANTI-LOCK BRAKES SYSTEM ANTI-LOCK BRAKES, INSTRUMENT CLUSTER SYSTEMS ANTI-LOCK BRAKES, INSTRUMENT CLUSTER, EXTERIOR LIGHTS SYSTEMS B-CAN TRANSCEIVER B-CAN TRANSCEIVER IC BATTERY JUNCTION BLOCK BURGLAR ALARM HORN BURGLAR ALARM HORN RLY C-CAN TRANSCEIVER DOOR LOCK RLY CTRL DOOR UNLOCK DOOR LOCK DRIVER DOOR LOCK DRV DR LOCK UNLOCK SIG IGN COIL CTRL CYL 1 IGN COIL CTRL CYL 2 IGN COIL CTRL CYL 3 IGN COIL CTRL CYL 4 IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 IGNITION COIL 5 IGNITION COIL 6 IGNITION COIL CTRL 1 IGNITION COIL CTRL 2 IGNITION COIL CTRL 3 IGNITION COIL CTRL 4 IGNITION COIL CTRL 5 INJECTOR CTRL 6 HIGH IGNITION COIL CTRL 6 LEFT HORN LH REAR DR DRV LOCK/ DR UNLOCK SW SIG LOCK SW LOCK UNLOCK M-CAN TRANSCEIVER PASS DR LOCK UNLOCK SIG PASSENGER DOOR LOCK RH REAR DR RH LOCK/ REAR UNLOCK DR SW SIG RIGHT HORN RR LH DOOR LOCK/ RR RH DOOR LOCK/ W/ MOBIS AMPLIFIER WINDOW LOCK IND

(RIGHT FRONT OF ENGINE ACTUATOR OUTPUT AUTO DEFOGGER ACTUATOR AUTO DEFOGGER ACTUATOR CLOSE AUTO DEFOGGER ACTUATOR F/B AUTO DEFOGGER ACTUATOR OPEN BLDC MOTOR BLOWER MOTOR CHECK ENGINE IND CONSOLE ON/OFF ACTUATOR CONSOLE ON/OFF ACTUATOR F/B CONSOLE ON/OFF ACTUATOR OFF CONSOLE ON/OFF ACTUATOR ON CONSOLE TEMP ACTUATOR COOL CONSOLE TEMP ACTUATOR WARM CONSOLE TEMPERATURE ACTUATOR DRIVER CUSHION MOTOR DRIVER DOOR LOCK ACTUATOR DRIVER FRONT HEIGHT ADJUSTER MOTOR DRIVER REAR HEIGHT ADJUSTER MOTOR DRIVER RECLINING MOTOR DRIVER SLIDE MOTOR DRIVER TEMP ACTUATOR COOL DRIVER TEMP ACTUATOR F/B DRIVER TEMP ACTUATOR WARM DRIVER TEMPERATURE ACTUATOR E-CVVT MOTOR ELECTRIC WASTEGATE ACTUATOR ENGINE CONTROL SYSTEM ENGINE CONTROLS SYSTEM ENGINE CTRL RLY CTRL ENGINE RPM ENGINE SPD OUTPUT FOLDING MOTOR FRONT AIR VENTILATION SEAT BLOWER MOTOR FRONT WASHER MOTOR SW POWER FUEL FILLER ACTUATOR FUEL SENDER, FUEL PUMP MOTOR HAPTIC STEERING WHEEL MOTOR INTAKE ACTUATOR INTAKE ACTUATOR F/B INTAKE ACTUATOR FRE INTAKE ACTUATOR REC LEFT ELECTRONIC PARKING BRAKE ACTUATOR LEFT FRONT AIR VENTILATION SEAT BLOWER MOTOR LEFT HEADLAMP LEVELING DEVICE ACTUATOR LEFT REAR DOOR LOCK ACTUATOR LOWER RIGHT FRONT OF ENGINE) MODE ACTUATOR DEF MODE ACTUATOR F/B MODE ACTUATOR VENT MOTOR A MOTOR B P-CAN LOW START MOTOR CTRL SW CLUTCH SW PARKING RELEASE ACTUATOR PASSENGER DOOR LOCK ACTUATOR PASSENGER FRONT HEIGHT ADJUSTER MOTOR PASSENGER REAR HEIGHT ADJUSTER MOTOR PASSENGER RECLINING MOTOR PASSENGER SLIDE MOTOR PASSENGER TEMP ACTUATOR COOL PASSENGER TEMP ACTUATOR F/B PASSENGER TEMP ACTUATOR WARM PASSENGER TEMPERATURE ACTUATOR PTC MOTOR RIGHT ELECTRONIC PARKING BRAKE ACTUATOR RIGHT FRONT AIR VENTILATION SEAT BLOWER MOTOR RIGHT HEADLAMP LEVELING DEVICE ACTUATOR RIGHT REAR DOOR LOCK ACTUATOR START MOTOR START MOTOR CTRL RLY START RLY CTRL START SOLENOID START MOTOR VARIABLE CHARGE MOTION ACTUATOR WASHER MOTOR WIPER MOTOR

ANTENNA 1 GND ANTENNA 1 GROUND ANTENNA 1 POWER ANTENNA 1 PWR ANTENNA 2 GROUND ANTENNA 2 POWER ANTENNA 2 PWR ANTENNA PWR BUMPER ANTENNA GROUND BUMPER ANTENNA POWER BUMPER ANTENNA PWR COMBINATION ANTENNA DRIVER DOOR ANTENNA GROUND DRIVER DOOR ANTENNA POWER DRV DOOR ANTENNA GND DRV DOOR ANTENNA PWR PASS DOOR ANTENNA GND PASS DOOR ANTENNA PWR PASSENGER DOOR ANTENNA GROUND PASSENGER DOOR ANTENNA POWER RIGHT GLASS ANTENNA SMART KEY ANTENNA SMART KEY BUMPER ANTENNA SMART KEY CONSOLE ANTENNA SMART KEY TRUNK ANTENNA TRUNK ANTENNA GND TRUNK ANTENNA GROUND TRUNK ANTENNA POWER TRUNK ANTENNA PWR

START/STOP BUTTON SWITCH VOLTAGE REGULATOR

(REAR VIEW CAMERA, SURROUND CAMERA P GND CAMERA P GND VIDEO Y GND CAMERA V GND CAMERA PWR CAMERA V GND CAMERA V IN DRIVER DOOR CAMERA FRONT VIEW CAMERA FRONT VIEW CAMERA GND FRONT VIEW CAMERA PWR FRONT VIEW CAMERA SIG LEFT SIDE CAMERA GND LEFT SIDE CAMERA PWR LEFT SIDE CAMERA SIG PASSENGER DOOR CAMERA REAR VIEW CAMERA REAR VIEW CAMERA CIRCUIT REAR VIEW CAMERA GND REAR VIEW CAMERA PWR REAR VIEW CAMERA SIG RIGHT SIDE CAMERA GND RIGHT SIDE CAMERA PWR RIGHT SIDE CAMERA SIG VIDEO Y SIG CAMERA V IN W/ REAR VIEW CAMERA W/O REAR VIEW CAMERA

DATA LINK CONNECTOR MULTI-PURPOSE CHECK CONNECTOR

A/C CONTROL MODULE DRIVER IMS CONTROL MODULE FRONT AIR VENTILATION SEAT CONTROL MODULE FRONT SEAT WARMER CONTROL MODULE FUEL PUMP CONTROL MODULE FUEL PUMP CONTROL MODULE SHIELD IPS CONTROL MODULE REAR SEAT WARMER CONTROL MODULE RIGHT FRONT AIR VENTILATION SEAT CONTROL MODULE SMART CRUISE CONTROL MODULE SRS CONTROL MODULE

AFS CONTROL UNIT B+ ECU DRIVER AIR LUMBAR CONTROL UNIT ECS UNIT ECU 1 FUSE ECU 2 FUSE ECU 3 FUSE ECU B+ ECU GND ECU GROUND ESC UNIT ESC UNIT ESC MODULE IMS ECU B+ LEFT BLIND-SPOT COLLISION WARNING UNIT LIN SAFETY ECU MDPS UNIT MULTI-FUNCTION CAMERA UNIT RIGHT BLIND-SPOT COLLISION WARNING UNIT RIGHT HAND BLIND-SPOT COLLISION WARNING UNIT SAFETY WINDOW ECU

A/BAG IND FUSE A/C 1 FUSE A/C 2 FUSE A/C FUSE ACC FUSE AIR BAG FUSE ALT FUSE AMP 1 FUSE AMP 2 FUSE AMS FUSE B+1 FUSE B+2 FUSE B+3 FUSE B+4 FUSE B+5 FUSE B+6 FUSE B/ALARM HORN FUSE BLOWER FUSE CHARGER FUSE CLUSTER FUSE COOLING FAN 1 FUSE COOLING FAN 2 FUSE DDM FUSE DOOR LOCK FUSE E-CVVT 1 FUSE E-CVVT 2 FUSE E-CVVT 3 FUSE E-SHIFTER 1 FUSE E-SHIFTER 2 FUSE ECS FUSE ESC 1 FUSE ESC 2 FUSE ESC 3 FUSE FUEL PUMP FUSE FUSE SWITCH FUSE SWITCH CTRL H/LAMP HI FUSE HEATED MIRROR FUSE HORN FUSE IBU 1 FUSE IBU 2 FUSE IBU 3 FUSE IBU 4 FUSE INTERIOR LAMP FUSE MDPS FUSE MEMORY 1 FUSE MODULE 1 FUSE MODULE 2 FUSE MODULE 3 FUSE MODULE 4 FUSE MODULE 5 FUSE MODULE 6 FUSE MODULE 7 FUSE MODULE 8 FUSE MODULE 9 FUSE MODULE FUSE MULTI FUSE 1 MULTI FUSE 2 MULTI MEDIA 1 FUSE MULTI MEDIA 2 FUSE MULTI MEDIA 3 FUSE MULTIMEDIA 1 FUSE MULTIMEDIA 2 FUSE MULTIMEDIA 3 FUSE OPCU FUSE P/SEAT PASS FUSE P/WINDOW LH FUSE P/WINDOW RH FUSE POWER HANDLE FUSE POWER OUTLET FUSE REAR HEATED FUSE S/HEATER DRV FUSE S/HEATER DRV/PASS FUSE S/HEATER REAR FUSE START FUSE STOP LAMP FUSE STOP SW FUSE SUNROOF 1 FUSE TCU 1 FUSE TCU 2 FUSE TRUNK FUSE VACUUM PUMP 1 FUSE WASHER FUSE WIPER 1 FUSE WIPER 2 FUSE

BACK HEATER CUSHION HEATER HEATER GND HEATER PAD STEERING WHEEL HEATER STEERING WHEEL HEATER SW STEERING WHEEL HEATER SW HIGH STEERING WHEEL HEATER SW LOW

FRONT WIRELESS CHARGER INDICATOR HAZARD SWITCH INDICATOR HIGH INDICATOR LOW INDICATOR SECURITY INDICATOR

BACKUP LAMP BACKUP LAMP SIG BRAKE LAMP SW CENTER ROOM LAMP DEFOGGER, EXTERIOR LIGHTS, NAVIGATION SYSTEMS DOOR LOCKS, INTERIOR LIGHTS, ANTI-THEFT SYSTEMS DRIVER FOOT LAMP FOOT LAMP OUT GLOVE BOX LAMP) HEADLIGHTS, EXTERIOR LIGHTS SYSTEMS HIGH MOUNTED STOP LAMP HIGH- MOUNTED STOP LAMP FILTER LEFT DRL LAMP LEFT LICENSE LAMP LEFT LUGGAGE LAMP LEFT SIDE LICENSE LAMP LEFT TURN LAMP LEFT TURN SIGNAL LAMP LEFT VANITY LAMP LH FRONT TURN LAMP LUGGAGE LAMP OUT MOOD LAMP OUT OVERHEAD CONSOLE LAMP PARKING LAMP PASSENGER FOOT LAMP POCKET LAMP PUDDLE LAMP PUDDLE/POCKET LAMP RH FRONT TURN LAMP RIGHT DRL LAMP RIGHT LICENSE LAMP RIGHT LUGGAGE LAMP RIGHT SIDE LICENSE LAMP RIGHT TURN LAMP RIGHT TURN SIGNAL LAMP RIGHT VANITY LAMP ROOM LAMP ROOM LAMP OUT STOP LAMP STOP LAMP LOW SW STOP LAMP SIG STOP LAMP SIG STOP SIG STOP LAMP SW TAIL LAMP TURN LAMP TURN SIG LAMP SW OUT WIPER/WASHER, EXTERIOR LIGHTS SYSTEMS

ELECTRIC OIL PUMP INVERTER ELECTRIC OIL PUMP MODULE ELECTRONIC OIL PUMP MODULE ELECTRONIC VACUUM PUMP FUEL PUMP FUEL PUMP GND FUEL PUMP RLY CTRL FUEL PUMP U FUEL PUMP V FUEL PUMP W HIGH PRESSURE FUEL PUMP PUMP OUTPUT VACUUM PUMP SIG IN

A/C RELAY ACC RELAY ACC RELAY CONTROL B/ALARM HORN RELAY BLOWER RELAY BURGLAR ALARM HORN RELAY DOOR LOCK RELAY DOOR UNLOCK RELAY E-CVVT RELAY ENGINE CONTROL RELAY FRONT WIPER HIGH RELAY FUEL LID RELAY FUEL PUMP RELAY HEADLAMP HIGH RELAY HORN RELAY HOT W/ ACC RELAY ENERGIZED HOT W/ ENGINE CONTROL RELAY ENERGIZED HOT W/ LEAK CURRENT AUTO CUT RELAY ENERGIZED LEAK CURRENT AUTO CUT DEVICE RELAY LEAK CURRENT AUTO CUT RELAY CONTROL P/N RELAY P/N RELAY CTRL PASSENGER WALK IN RELAY MODULE REAR DEFOGGER RELAY CONTROL REAR HEATED RELAY RELAY ENERGIZED START RELAY START RELAY LDC START RELAY OUTPUT T/TURN UNLOCK RELAY TRUNK RELAY TWO TURN UNLOCK RELAY VACUUM PUMP RELAY WIPER HIGH RELAY CONTROL WIPER LOW RELAY CONTROL WIPER POWER RELAY WIPER POWER RELAY CONTROL

ACCEL PEDAL POSITION SENSOR AMBIENT TEMPERATURE SENSOR AUTO DEFOGGER SENSOR AUTO LIGHT, PHOTO SENSOR BATTERY SENSOR BODY G-SENSOR FL SIGNAL BODY G-SENSOR FR SIGNAL BODY G-SENSOR RR SIGNAL BOOSTER PRESSURE SENSOR BRAKE BOOSTER VACUUM PRESSURE SENSOR BRAKE FLUID LEVEL SENSOR CRANKSHAFT POSITION SENSOR DRIVER DOOR SIDE IMPACT PRESSURE SENSOR DRIVER FRONT IMPACT SENSOR DRIVER FRONT SIDE IMPACT SENSOR DRIVER REAR SIDE IMPACT SENSOR ENGINE COOLANT TEMPERATURE SENSOR ETC MOTOR, THROTTLE POSITION SENSOR ETC MOTOR, THROTTLE POSITION SENSOR SHIELD EVAPORATOR SENSOR FUEL PRESSURE SENSOR FUEL RAIL PRESSURE SENSOR FUEL TANK PRESSURE SENSOR INCAR SENSOR INDICATOR SWITCH SENSOR INPUT SPEED SENSOR INTAKE TEMPERATURE SENSOR KNOCK SENSOR KNOCK SENSOR #2 LEFT FRONT BODY ECS G-SENSOR LEFT FRONT TIRE PRESSURE SENSOR LEFT FRONT WHEEL ECS G-SENSOR LEFT FRONT WHEEL SENSOR LEFT REAR ECS G-SENSOR LEFT REAR TIRE PRESSURE SENSOR LEFT REAR WHEEL ECS G-SENSOR LEFT REAR WHEEL SENSOR MAP SENSOR 1 MAP SENSOR 2 OIL PRESSURE/ TEMPERATURE SENSOR OIL TEMP SENSOR OIL TEMPERATURE SENSOR OUTPUT SPEED SENSOR PASSENGER DOOR SIDE IMPACT PRESSURE SENSOR PASSENGER FRONT IMPACT SENSOR PASSENGER FRONT SIDE IMPACT SENSOR PASSENGER OCCUPANT DETECTION SENSOR PASSENGER REAR SIDE IMPACT SENSOR PHOTO SENSOR RAIN SENSOR RAIN SENSOR LIN REAR ECS G-SENSOR RIGHT FRONT BODY ECS G-SENSOR RIGHT FRONT TIRE PRESSURE SENSOR RIGHT FRONT WHEEL ECS G-SENSOR RIGHT FRONT WHEEL SENSOR RIGHT REAR ECS G-SENSOR RIGHT REAR TIRE PRESSURE SENSOR RIGHT REAR WHEEL ECS G-SENSOR RIGHT REAR WHEEL SENSOR SENSOR 1 FUSE SENSOR 2 FUSE SENSOR 3 FUSE SENSOR 4 FUSE SENSOR 5 FUSE SENSOR GND SENSOR GROUND SENSOR IN SENSOR OUT SENSOR POWER SENSOR POWER COM SENSOR PWR SENSOR SUPPLY STEERING ANGLE SENSOR THROTTLE POSITION SENSOR TRANSMISSION PARK POSITION SENSOR/ SWITCH TRANSMISSION PARK POSITION SENSOR/SWITCH WASHER LEVEL SENSOR WHEEL G-SENSOR WHEEL G-SENSOR FL SIGNAL WHEEL G-SENSOR FR SIGNAL WHEEL SENSOR WHEEL SPEED SENSOR

CENTER SPEAKER CLUSTER SPEAKER DRIVER DOOR SPEAKER DRIVER DOOR TWEETER SPEAKER DRIVER MID RANGE SPEAKER LEFT REAR DOOR SPEAKER LEFT REAR DOOR TWEETER SPEAKER LEFT REAR SURROUND SPEAKER LEFT WOOFER SPEAKER PASSENGER DOOR SPEAKER PASSENGER DOOR TWEETER SPEAKER PASSENGER MID RANGE SPEAKER RIGHT REAR DOOR SPEAKER RIGHT REAR DOOR TWEETER SPEAKER RIGHT REAR SURROUND SPEAKER RIGHT WOOFER SPEAKER SPEAKER OUT -

A/C SWITCH AJAR SWITCH AUTO HOLD SWITCH BACKUP LAMP SWITCH BCW SWITCH BRAKE SWITCH SIG BRAKE VACUUM SWITCH CLUTCH SWITCH CONSOLE SWITCH CRASH PAD SWITCH CUSHION SWITCH DOOR LOCK SWITCH DOOR UNLOCK SWITCH DRIVER AIR VENTILATION SEAT SWITCH DRIVER CUSHION SWITCH DRIVER DOOR LOCK/UNLOCK SWITCH DRIVER DOOR SWITCH DRIVER FRONT HEIGHT ADJUSTER SWITCH DRIVER IMS SWITCH DRIVER REAR HEIGHT ADJUSTER SWITCH DRIVER RECLINING LIMIT SWITCH DRIVER RECLINING SWITCH DRIVER SEAT BELT BUCKLE SWITCH DRIVER SEAT BELT SWITCH DRIVER SEAT MANUAL SWITCH DRIVER SEAT WARMER SWITCH DRIVER SLIDE SWITCH DRV DOOR LOCK/UNLOCK SWITCH ELECTRIC PARKING BRAKE SWITCH ESC OFF SWITCH FOOT PARKING BRAKE SWITCH FRONT HEIGHT ADJUSTER SWITCH FRONT WASHER SWITCH FUEL LID OPEN SWITCH FULL LOCK SWITCH GLOVE BOX LAMP/ SWITCH HAND PARKING BRAKE SWITCH HAZARD SWITCH HEADLAMP HI SWITCH HEATED STEERING WHEEL SWITCH HOOD SWITCH HORN SWITCH IGNITION LOCK SWITCH IGNITION LOCK, CLUTCH SWITCH INT/VOL SWITCH ISG OFF SWITCH ISG OFF SWITCH IND LDW/LKA-L/R SWITCH LEFT AUDIO/ BLUETOOTH REMOTE CONTROL SWITCH LEFT REAR DOOR SWITCH LEFT REAR POWER WINDOW SWITCH LEFT REAR SEAT WARMER SWITCH LEFT VANITY LAMP SWITCH LIGHT SWITCH SIG LIGHT SWITCH SIGNAL LIMIT SWITCH M/T SHIFT LEVER R SWITCH MULTI- FUNCTION SWITCH NEUTRAL SWITCH OIL PRESSURE SWITCH ON/OFF SWITCH OVERHEAD CONSOLE SWITCH P POSITION SWITCH PARKING BRAKE SWITCH PARKING SWITCH PASS DOOR LOCK/UNLOCK SWITCH PASS SEAT BELT SWITCH PASSENGER AIR VENTILATION SEAT SWITCH PASSENGER DOOR LOCK/UNLOCK SWITCH PASSENGER DOOR SWITCH PASSENGER RECLINING LIMIT SWITCH PASSENGER SEAT BELT BUCKLE SWITCH PASSENGER SEAT MANUAL SWITCH PASSENGER SEAT WARMER SWITCH PASSENGER WALK IN SWITCH PDW-F/R SWITCH PDW-F/R SWITCH IN REAR DEFOGGER SWITCH REAR DEFOGGER SWITCH INPUT REAR HEIGHT ADJUSTER SWITCH RECLINING LIMIT SWITCH RECLINING SWITCH RETURN HAZARD LAMP SWITCH RIGHT REAR DOOR SWITCH RIGHT REAR POWER WINDOW SWITCH RIGHT REAR SEAT WARMER SWITCH RIGHT TRIP/CRUISE CONTROL SWITCH RIGHT TRIP/CRUISE REMOTE CONTROL SWITCH RIGHT VANITY LAMP SWITCH RMS SWITCH RMS SWITCH INPUT RR LH DOOR SWITCH SIGNAL RR RH DOOR SWITCH SIGNAL SEAT BELT BUCKLE SWITCH INPUT SLIDE SWITCH STEERING TILT, TELESCOPIC SWITCH STOP LAMP SWITCH SUNROOF SWITCH SVM SWITCH SWITCH SIGNAL TELL TALE SWITCH TRIP SWITCH TRUNK HANDLE SWITCH TRUNK LID HANDLE SWITCH TRUNK LID SWITCH TRUNK OPEN SWITCH TURN LAMP SWITCH SIGNAL WASHER FLUID SWITCH WASHER SWITCH WINDOW LOCK SWITCH WIPER B/UP SWITCH SIGNAL WIPER LOW SWITCH

CANISTER CLOSE VALVE ELECTRONIC CONTROL VALVE HIGH BEAM SOLENOID OIL CONTROL VALVE OIL PRESSURE SOLENOID VALVE PURGE CONTROL SOLENOID VALVE RECIRCULATION VALVE CONTROL SOLENOID VALVE SOLENOID VALVE START SOLENOID VARIABLE OIL PUMP SOLENOID VOLUME CTRL VALVE HIGH VOLUME CTRL VALVE LOW

(OR RED/ WIRE B-CAN LOW PNK B-CAN HIGH WIRE BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/ORG WIRE BRN/WHT WIRE BUMPER ANTENNA GND PNK ANTENNA 2 GND WIRE GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/ORG WIRE GRY/RED WIRE LED GREEN LT GRN WIRE NCA WIRE ON/START IN SHIELD WIRE GND GND ORG/ WIRE ORG/BLK WIRE PNK ACC RLY CTRL WIRE PNK ON/START I/P C-CAN HIGH WIRE PNK RLY CTRL ACC WIRE PNK WIRE PNK/BLK WIRE PNK/ORG WIRE RED WIRE RED/BLK WIRE RED/ORG WIRE RED/WHT WIRE VIO WIRE WHT WIRE WHT/BLK WIRE WHT/ORG WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/ORG WIRE YEL/WHT WIRE YELLOW IND

2.0L TURBO 3.3L TURBO 3.5 MONO TFT LCD TFT CONTROL SIG "ON" "P" (CONVENTIONAL (NOT (RIGHT SIDE OF TRANSMISSION (SURROUND VIEW +B RADIO A/BAG IND A/C PRESSURE TRANSDUCER A/C RLY CTRL A/T M/T ABS IND. ACC/ON I/P ACC/ON INPUT ACC/ON O/P ACC/ON OUTPUT ACTIVE AIR FLAP MODULE AIR BAG AIR BAG IND AIR CONDITIONING SYSTEM ALL DEFLATION SIG AMP DAC ANT-G ANT-R ANT-ST ANTI-THEFT ANTI-THEFT SYSTEM APS 1 GND APS 1 GROUND APS 1 SIG APS 1 SIGNAL APS 1 SPLY APS 2 GND APS 2 GROUND APS 2 SIG APS 2 SIGNAL APS 2 SPLY AST AUTO SW AST SBR MAT AST WINDOW AUTO DOWN AST WINDOW AUTO UP AST WINDOW DOWN AST WINDOW DOWN SW AST WINDOW UP AST WINDOW UP SW AUTO CUT RLY CTRL AUTO DOWN AUTO HEADLAMP LEVELING DEVICE MODULE AUTO HIGH BEAM IND AUTO HOLD SW SIG IN AUTO LIGHT AUTO LIGHT INTERFACE GROUND AUTO LIGHT INTERFACE POWER AUTO LIGHT INTERFACE SIGNAL AUTO UP AUX DET AUX DETECT AUX GND AUX L + AUX L IN AUX R + AUX R IN AUX, USB JACK B+ PWR B-CAN B-CAN HI B-CAN HIGH B-CAN IC B-CAN LO B-CAN LOW B/B-AMS B/B-RS B/B-ST BACK B+ BACKUP COMM BACKUP LAMPS CIRCUIT BACKUP SIG BACKUP SW OUT BCW IND BODY K-LINE BODY LOAD BOLSTER SIG DEF BOLSTER SIG INF BRAKE FLUID BRAKE FLUID LEVEL BRAKE FLUID LEVEL SENS BRAKE LIGHT BRAKE LIGHT SW BRAKE TEST SW BRAKING SW BRK LIGHT SW C-CAN C-CAN C-CAN LOW HIGH C-CAN HIGH C-CAN LOW CCV CTRL CHARGE IND CHASSIS GND CLIMATE LOCAL LIN CLOCK- SPRING CLUTCH SW COAXIAL CABLE COMPUTER DATA LINES COMPUTER DATA LINES SYSTEM CONSTANT CURRENT CONVENTIONAL SUPERVISION COOLING FAN CONTROLLER COOLING FANS SYSTEM CRASH OUTPUT CRASH UNLOCK CRUISE CONTROL SYSTEM CTR + CUSH B+ CVVT EXHAUST BANK 1 CVVT EXHAUST BANK 2 CVVT INTAKE BANK 1 CVVT INTAKE BANK 2 D-CAN D-SOL 4, OD D-SOL 6 D-SOL 27 D-SOL UD DATA LINE DATA LINES DEFOGGER SYSTEM DETENT OUT DIMMING CONTROL DIMMING POWER DISP MUTE DN UP DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR OPEN SIG DOOR SW DOOR UNLOCK RLY CTRL DOOR/ ROOM DOWN/ AUTO DOWN DRIVE MODE DRIVE MODE SW CCW IN DRIVE MODE SW CW IN DRIVE MODE SW CWW IN DRIVER AIR BAG DRIVER C-PILLAR + DRIVER CURTAIN AIR BAG DRIVER DOOR DRIVER DOOR MODULE DRIVER FRONT SIDE AIR BAG DRIVER HIGH DRIVER KNEE AIR BAG DRIVER LOW DRIVER POWER OUTSIDE MIRROR DRIVER SAFETY POWER WINDOW MODULE DRIVER SEAT BELT ANCHOR PRETENSIONER DRIVER SEAT BELT PRETENSIONER DRIVER SMART KEY OUTSIDE HANDLE DRV AIR DRV AIR VENT SEAT SW DRV CUSHION MTR BWD DRV CUSHION MTR FWD DRV CUSHION MTR SIG DRV CUSHION SW BWD DRV CUSHION SW FWD DRV DR SW DRV FRT HEIGHT MTR DN DRV FRT HEIGHT MTR SIG DRV FRT HEIGHT MTR UP DRV FRT HEIGHT SW DN DRV FRT HEIGHT SW UP DRV RECLINING MTR BWD DRV RECLINING MTR FWD DRV RECLINING MTR SIG DRV RECLINING SW BWD DRV RECLINING SW FWD DRV RR HEIGHT MTR DN DRV RR HEIGHT MTR SIG DRV RR HEIGHT MTR UP DRV RR HEIGHT SW DN DRV RR HEIGHT SW UP DRV SEAT WARMER DRV SEAT WARMER SW DRV SLIDE MTR BWD DRV SLIDE MTR FWD DRV SLIDE MTR SIG DRV SLIDE SW BWD DRV SLIDE SW FWD DRV WINDOW AUTO DOWN DRV WINDOW AUTO UP DRV WINDOW DOWN DRV WINDOW UP E-CVVT RLY CTRL E THERMOSTAT CTRL PWM OUTPUT E-CVVT RLY ON INPUT E/R JUNCTION BLOCK E/R-A E/R-B E/R-C E/R-D E/R-E E/R-F ECM MIRROR ECTS SIG ECTS GND ELECTROCHROMIC MIRROR ELECTROCHROMIC MIRROR CIRCUIT ELECTRONIC A/C COMPRESSOR ELECTRONIC ATM SHIFT LEVER ELECTRONIC ATM SHIFTER LEVER ELECTRONIC THERMOSTAT EMPTY FUEL LEVEL FLOAT EMS COM ENG CTRL RLY CTRL ENG CTRL RLY ON INPUT ENG SPD ENG SPEED OUTPUT EPB IND EPB SW 1 EPB SW 2 EPB SW 3 EPB SW 4 ESC IND ESC MODULE ESC OFF IND ESC OFF SW SIG IN EXT BUZZER EXTERNAL BUZZER FCA OFF IND FET DRAIN FET GATE FL SIG FL VCC FLASH MEMORY FPS GND FPS PWR FPS SIG FR GND FR SIG FR VCC FRONT HEIGHT ADJUSTER MTR DOWN FRONT HEIGHT ADJUSTER MTR UP FRONT MONITOR FRONT MONITOR SHIELD FRONT POWER OUTLET FRONT USB CHARGER FRONT WASHER SW SIG FRONT WIPER LOW BACKUP SIG FRONT WIPER RLY CTRL HIGH FRONT WIPER RLY CTRL LOW FRONT WIRELESS CHARGER FUEL GAUGE FUEL SENDER FUEL SUB SENDER FUEL TANK FUEL TANK LEVEL SENDER FUEL TANK LEVEL SENDER 2 FUEL TANK LVL SENDER 1 FUEL TANK LVL SENDER 2 GND B-CAN LOW GND SIG 1 GPS OUT/VIN GROUND DISTRIBUTION SYSTEM HALL IC OUT DIR HALL IC OUT GND HALL IC OUT PWR HALL IC OUT SPD HALL IC SIG IN CNT HALL IC SIG IN DIR HALL IC SIG IN GND HALL IC SIG IN PWR HANDLE SW HAZARD SW IND HEAD-UP DISPLAY HEADLAMP HIGH SW IN HEADLAMP LOW HEADLAMP LOW SIG HEADLAMP LOW SIGNAL HEADLIGHTS SYSTEM HIGH BEAM IND HIGH IND HIGH LOW HIGH SW OUT HOOD SW HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START HOT W/ HTD STEERING WHL SW I/P-A I/P-B I/P-C I/P-D I/P-E I/P-F I/P-G I/P-G I/P-C IAT SENS IC IGNITER ICU ENABLE ICU JUNCTION BLOCK IGN 1 IMMO DATA LINE IMMO GND IMMO GROUND IMMO IND IMMO POWER IMMO PWR IMS SW IMS SW IN IN SPEED POWER INHIBITOR SW INHIBITOR SW SIG INHIBITOR SW SIG GND INJ CTRL 1 HIGH INJ CTRL 1 LOW INJ CTRL 2 HIGH INJ CTRL 2 LOW INJ CTRL 3 HIGH INJ CTRL 3 LOW INJ CTRL 4 HIGH INJ CTRL 4 LOW INJECTOR 1 INJECTOR 2 INJECTOR 3 INJECTOR 4 INJECTOR 5 INJECTOR 6) INJECTOR CTRL 1 HIGH INJECTOR CTRL 1 LOW INJECTOR CTRL 2 HIGH INJECTOR CTRL 2 LOW INJECTOR CTRL 3 HIGH INJECTOR CTRL 3 LOW INJECTOR CTRL 4 HIGH INJECTOR CTRL 4 LOW INJECTOR CTRL 5 HIGH INJECTOR CTRL 5 LOW INJECTOR CTRL 6 LOW INPUT SPD SIG INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM INSTRUMENT ILLUMINATION CIRCUIT INT/VOL SW INT/VOL SW SIG IPS 1 IPS 1 CONTROL IPS 1 CTRL IPS 2 IPS 2 CONTROL IPS 2 CTRL IPS 4 IPS 4 CONTROL IPS 4 CTRL IPS 5 IPS 5 CONTROL IPS 5 CTRL IPS 6 IPS 6 CTRL IPS 7 IPS 7 CTRL IPS 9 IPS 9 CTRL IPS 10 CTRL IPS CONTROL IPS MIRROR/ FOLDING ISG OFF SW ISG OFF SW IND ISG SIG INPUT ISG SIGNAL IN K LINE L ISG SIG L LF IN L_MT LBA-D IND LCD DRV EN LCD GND LDC B+ INPUT LDW/LKA-L/R LEAK CURRENT LEAK CURRENT AUTO CUT DEVICE LED CONTROL LOGIC LED HEADLAMP IND LEFT FRONT AIR VENTILATION SEAT WARMER LEFT FRONT SEAT WARMER LEFT HEADLAMP LEFT MAP SW LEFT REAR POWER WINDOW MODULE LEFT REAR SAFETY POWER WINDOW MODULE LEFT REAR SEAT WARMER MAT LEFT RIGHT LEFT TURN IND LEVEL POSITION LEVEL SENDER 1 LEVEL SENDER 2 LEVEL SENS LEVER) LF HTR HIGH IND LF HTR MID IND LF HTR SW SIG LF SEARCHING ON LF SIG LF TURN LP TELL- TALE SW LF VCC LH BLOWER PWR B+ LH BLOWER SPEED CTRL LH HEADLAMP LOW LH HTR BACK B+ LH HTR CUSH GND LH HTR CUSHION B+ LH REAR DR SW LIGHT GND LIGHT SW LIGHT SW OUT LIGHT SW SIG LIN COMMUNICATION LIN LINE LIN PDW LIN RAIN LIN SAFETY LOCAL CAN HIGH LOCAL CAN LOW LOW BEAM IND LOW FUEL IND LOW HIGH LOW IND LOW IND MID IND LOW SIGNAL LOW SPEED OUT LOW TELLTALE LR DR SW LR SEAT WARMER MAT LR SEAT WARMER SW HIGH IND LR SEAT WARMER SW LOW IND LR SEAT WARMER SW MID IND LR VCC LUMBAR SIG BWD LUMBAR SIG DOWN LUMBAR SIG FWD LUMBAR SIG UP LVDS HI LVDS HIGH LVDS LO LVDS LOW M HOR M VER M-CAN M-CAN HIGH M-CAN LOW M/T A/T M/T, SMART KEY MAP SW MASTER IND MATCHING CIRCUIT MDPS IND MEM PWR MEM PWR O/P MEMORY POWER MEMORY POWER INPUT MEMORY POWER OUTPUT MEMORY PWR MEMORY PWR I/P MEMORY PWR INPUT MEMORY PWR O/P MEMORY PWR OUTPUT MEMORY SYSTEMS MIC - MIC GND MIC HANDSFREE MIC IN - MID IND MIRROR DOWN MIRROR FOLD- MIRROR LEFT MIRROR RIGHT MIRROR SELECT L MIRROR SELECT R MIRROR UNFOLD MIRROR UP MIRRORS SYSTEM MIRRORS, MEMORY SYSTEMS MODULE 6 MONITOR CIRCUIT MTR MONITORING MTR SW BWD MTR SW FWD NAVIGATION SYSTEM NEUTRAL SW NOISE FILTER NOT P NOT P POSITION NTC- OCV CTRL OIL PRESS SENS OIL PRESSURE IND OIL PRESSURE SW IN OIL TEMP SENS ON I/P ON INPUT ON/OFF DRIVE ON/OFF DRV ON/OFF PARK ON/OFF PARKING ON/OFF REV ON/OFF REVERSE ON/OFF SW SIG ON/START I/P ON/START IN ON/START INPUT OPEN WARNING ALARM OUT SPEED POWER OUTPUT SPD SIG OUTSIDE MIRROR OUTSIDE MIRROR CONTROL OUTSIDE MIRROR CTRL C OUTSIDE MIRROR CTRL HR OUTSIDE MIRROR CTRL VT OVER SPEED IND OXYGEN SENS DOWN GND OXYGEN SENS DOWN HTR OXYGEN SENS DOWN SIG OXYGEN SENS UP HTR OXYGEN SENS UP V-G OXYGEN SENS UP V-IP OXYGEN SENS UP V-N OXYGEN SENS UP V-RC P POSITION P-CAN P-CAN HIGH P-CAN LOW P-GND P/N RLY CTRL PAB OFF PADDLE SHIFT DOWN PADDLE SHIFT UP PARKING BRAKE PARKING BRAKE IND. PARKING DISTANCE WARNING FORWARD PWR PARKING DISTANCE WARNING REVERSE PWR PARKING SW PWR PAS/RPAS IND PASS AIR VENT SEAT SW PASS DR SW PASS SEAT VENT WARMER SEAT SW SW SW PASS SEAT WARMER SW PASSENGER AIR BAG 1 PASSENGER AIR BAG 2 PASSENGER CURTAIN AIR BAG PASSENGER DOOR MODULE PASSENGER DOOR) PASSENGER FRONT SIDE AIR BAG PASSENGER HIGH PASSENGER LOW PASSENGER LUMBAR MTR BWD PASSENGER LUMBAR MTR DOWN PASSENGER LUMBAR MTR FWD PASSENGER LUMBAR MTR UP PASSENGER POWER OUTSIDE MIRROR PASSENGER SAFETY POWER WINDOW MODULE PASSENGER SEAT BELT ANCHOR PRETENSIONER PASSENGER SEAT BELT PRETENSIONER PASSENGER SMART KEY OUTSIDE HANDLE PCB BLOCK PCSV CTRL PDW-F GND PDW-F GROUND PDW-F POWER PDW-F/R IND O/P PDW-F/R INPUT PDW-F/R SW I/P PDW-R POWER POWER DISTRBUTION SYSTEM POWER DISTRIBUTION SYSTEM POWER GROUND POWER TOPS SYSTEM POWER WINDOWS SYSTEM PRESS SENS GND PRESS SENS SIG PRESSURE SENS SUPPLY PUMPING CURRENT PWM OUTPUT PWM SIG PWR B PWR GND PWR OUT R-SW RADIO ANT RCV CTRL REAR DEFOGGER REAR DEFOGGER RLY CTRL REAR DEFOGGER SW REAR DEFOGGER SW IND REAR GND REAR HEIGHT ADJUSTER MTR DOWN REAR HEIGHT ADJUSTER MTR UP REAR SIG REAR SPLY REAR SUB JUNCTION BLOCK REAR USB CHARGER RECLINING LIMIT SW BWD RECLINING LIMIT SW FWD RECLINING LIMIT SW GND BWD RECLINING LIMIT SW GND FWD RECLINING MTR BWD RECLINING MTR FWD RECLINING SW BWD RECLINING SW FWD RETURN HAZARD SW RF HTR HIGH IND RF HTR MID IND RF HTR SW SIG RF SIG RF TURN LP TELL- TALE SW RF VCC RH BLOWER PWR B+ RH BLOWER SPEED CTRL RH FOLDING RH HEADLAMP LOW RH HR RH HTR BACK B+ RH HTR CUSH GND RH HTR CUSHION B+ RH UNFOLDING RH VT RHEOSTAT DOWN IN RHEOSTAT UP IN RIGHT END OF DASH) RIGHT FRONT AIR VENTILATION SEAT WARMER RIGHT FRONT SEAT WARMER RIGHT HEADLAMP RIGHT MAP SW RIGHT REAR SAFETY POWER WINDOW MODULE RIGHT REAR SEAT WARMER MAT RIGHT TURN IND RING ILL RL AUTO SW RL SIG RL VCC RL WINDOW DOWN SW RL WINDOW UP SW RLY CTRL RLY ON INPUT RMS SW I/P ROOM SW RR AUTO SW RR DR SW RR SEAT WARMER MAT RR SEAT WARMER SW HIGH IND RR SEAT WARMER SW LOW IND RR SEAT WARMER SW MID IND RR SIG RR VCC RR WINDOW DOWN SW RR WINDOW UP SW RS-A RS-B SEAT BELT IND SEATS SYSTEM SENS FEEDBACK SENS GND SENS HALL 1 SENS HALL 2 SENS INTERFACE SENS MTR HALL POWER SUPPLY SENS MTR RLY CTRL CCW SENS MTR RLY CTRL CW SENS SHIELD SENS SIG SENS SPLY SET- SHIELD GND SHIFT INTERLOCK, TRANSMISSIONS SYSTEMS SIG 1 GND SIG 3 GND SIG A SIG B SIG C SIG GND SIG-D SIGNAL GROUND SINGLE PISTON SLIDE MTR SPD I/P SPDIF GND SPDIF HIGH SPDIF LOW SPEED OUT SPEED SIG SSB ILL POWER SSB ILL PWR SSB ILL RING SSB RING SSB RING ILL OUT SSB SW 1 SSB SW 2 START F/B SIG START F/B SIGNAL START MTR CTRL RLY START MTR CTRL SW START MTR RLY CTRL START RLY CTRL START RLY LDC START RLY O/P STARTING/ CHARGING SYSTEM STARTING/CHARGING SYSTEM STATUS IND STEERING TILT, TELESCOPIC MODULE STEERING WHEEL HEATED MODULE STEERING WHEEL STEERING WHEEL HEATED MODULE STEERING WHEEL) STEP MTR HLLD ACTR STEP MTR ISM HLLD ACTR STOP LP SIG STOP LP SW STOP SIG SUNROOF ASSEMBLY SUNROOF STATUS SUNROOF STATUS IN SUPPLEMENTAL RESTRAINTS SYSTEM SURROUND VIEW MONITOR SVM DET SVM SW IND SVM SW SIG SW BWD SW FWD SW GND SW IND SW OUT SW SIG SW_IN SW_OUT SXM OUT/VIN SYMBOL ILL IND T/SIG LP FL T/SIG LP FR T/SIG LP RL T/SIG LP RR T/TURN UNLOCK RLY CTRL TAIL ON IND TCU POSITION TELESCOPIC IN TELESCOPIC OUT TELL TALE TELLTALE SW TEMPERATURE GAUGE TFT CONTROL SIGNAL TILT DOWN TILT UP TMU B+ TMU OUT TOP OF TRANSMISSION) TOUCH INT TOUCH RST TPMS IND TPS 1 SIG TPS 1 SIGNAL TPS 2 SIG TPS 2 SIGNAL TPS GND TPS GROUND TPS SPLY TPS SUPPLY TRANSMISSIONS SYSTEM TRIP SW GND TRIP SW SIG TRUNK FULL TRUNK FULL OPEN TRUNK LID LATCH TRUNK OPEN TRUNK OPEN SW TRUNK RLY CTRL TRUNK, TAILGATE, FUEL DOORS SYSTEM TURN LP SW SIG UNLOCK SIGNAL UP DOWN VACUUM SW SIG IN VBAT LCD VBATT MTR RLY VEHICLE SPD VEHICLE SPD INPUT VEHICLE SPEED INPUT VEHICLE SPEED SIG VFS DC VFS LP VIDEO C SHIELD VIDEO C-SIG VIDEO GND VIDEO OUT VIDEO SIG VIDEO SIG O/P C GND VIDEO SIG O/P C SIG VIDEO SIG O/P SHIELD VIDEO SIG O/P Y GND VIDEO SIG O/P Y SIG VIDEO Y GND VIDEO Y SHIELD VIDEO Y-SIG VIDEO-C GND VIEW MONITOR CIRCUITS) VOL 2 VOL 3 VOL 4 VR ACTUATION W/ AIR VENTILATION W/ AIRCELL LUMBAR SUPPORT W/ BCW W/ ECS W/ EPB W/ EPB W/O EPB W/ FOOT BRAKE W/ HAND BRAKE W/ ISG W/ ISG W/O ISG W/ ISG W/O ISG W/ TMU W/ LTE W/ LED W/ LED W/O LED W/ MEMORY W/ MEMORY W/O MEMORY W/ SVM W/ TMU W/ LTE W/ TWO TURN UNLOCK W/O TWO TURN UNLOCK W/ WALK IN W/O AIR VENTILATION W/O AIRCELL LUMBAR SUPPORT W/O BCW W/O ECS W/O EPB W/ EPB W/O ISG W/O LED W/O LED W/ LED W/O MEMORY W/O SVM W/O WALK IN WALK IN SW BWD WALK IN SW FWD WARNING IND WHEEL SENS SIG WIPER 'P' WIPER 'P' POSITION WIPER B/UP SW SIG WIPER LOW B/UP SIG WIPER LOW B/UP SIGNAL WIPER PWR RLY CTRL WIPER SW SIG WIPER, LIGHT GND WIPER, LIGHT GROUND WIPER/ WASHER SYSTEM WIPER/WASHER SYSTEM
