Car Wiring Diagrams for Power sliding door circuit for Ford Windstar I (1994-2003)

1 2 3 4 RETURN POWER LT UNLATCH GROUND 1 2 3 4 RETURN POWER RT UNLATCH GROUND BATTERY JUNCTION BOX FUSE 110 BLK WIRE BLU WIRE DATA LINK CONNECTOR DATA LINK IGNITION FUEL DOOR INTERLOCK SWITCH FUSE 10 FUSE 118 FUSE JUNCTION PANEL FUSE 6 GRY WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT IN RUN LEFT POWER SLIDING DOOR CLUTCH LEFT POWER SLIDING DOOR DETENT SWITCH LEFT POWER SLIDING DOOR LATCH REVERSE ACTUATOR LEFT POWER SLIDING DOOR LOCK ACTUATOR LEFT POWER SLIDING DOOR MOTOR LEFT POWER SLIDING DOOR POSITION SENSOR LEFT POWER SLIDING DOOR SWITCH LT BLU WIRE LT BLU/PNK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/RED WIRE NCA WIRE ORG/ WIRE OVERHEAD CONSOLE PNK/BLK WIRE REAR ELECTRONIC MODULE (AT RIGHT REAR QUARTER PANEL) RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT POWER SLIDING DOOR CLUTCH RIGHT POWER SLIDING DOOR LOCK ACTUATOR RIGHT POWER SLIDING DOOR MODULE (AT RIGHT REAR QUARTER PANEL) RIGHT POWER SLIDING DOOR MOTOR RIGHT POWER SLIDING DOOR POSITION SENSOR RIGHT POWER SLIDING DOOR SWITCH SLIDING DOOR CONTACT SLIDING DOOR CONTACTS SLIDING DOOR CONTACTS SLIDING DOOR CONTACT TAN WIRE TAN/BLK WIRE TAN/LT BLU WIRE TAN/RED WIRE VIO WIRE VIO/WHT WIRE WHT WIRE WHT/LT GRN WIRE YEL WIRE YEL/RED WIRE
