Car Wiring Diagrams for Charging circuit for Ford Windstar I (1994-2003)

BATTERY BATTERY JUNCTION BOX FUSE 20 (LEFT SIDE OF ENG COMPT) BLK WIRE CHARGE ILLUM COMPUTER DATA LINES FUSE 13 FUSIBLE LINK A FUSIBLE LINK B GENERATOR GRY WIRE HOT IN RUN OR START INSTRUMENT CLUSTER ORG/LT BLU WIRE PNK/LT BLU WIRE POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH, THROUGH FIREWALL) RED WIRE RED/PNK WIRE SCP - SCP + STARTER MOTOR SOLENOID TAN/ORG WIRE VIO WIRE YEL/WHT WIRE
