Power mirror circuit, with heated signal mirrors for Ford Windstar I (1994-2003)
Power mirror circuit, with heated signal mirrors
BLK WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DEFOGGER SYSTEM
DIREC- TIONAL CONTROL SWITCH
DK BLU WIRE
DK GRN WIRE
DK GRN/VIO WIRE
DOWN RIGHT
EXTERIOR REAR VIEW MIRROR SWITCH
FUSE
HOT AT ALL TIMES
L/R U/D
LEFT
LEFT EXTERIOR REAR VIEW MIRROR
LEFT TURN SIGNAL
NCA WIRE
ORG/LT GRN WIRE
PNK WIRE
RED WIRE
RIGHT
RIGHT EXTERIOR REAR VIEW MIRROR
RIGHT TURN SIGNAL
UP LEFT
VIO WIRE
VIO/WHT WIRE
YEL WIRE
