Car Wiring Diagrams for Instrument illumination circuit for Ford Windstar I (1994-2003)

ACCESSORY DELAY RELAY ADJUSTABLE PEDAL SWITCH BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) BLK WIRE CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) FUSE 18 CLIMATE CONTROL SWITCH ASSEMBLY DK BLU/LT GRN WIRE FRONT ELECTRONIC MODULE (BELOW LEFT SIDE OF DASH) FUSE 106 HOT AT ALL TIMES INSTRUMENT CLUSTER KICK PANEL) LT BLU WIRE LT BLU/BLK WIRE LT BLU/WHT WIRE LT GRN/RED WIRE MAIN LIGHT SWITCH MASTER WINDOW/ DOOR LOCK/UNLOCK SWITCH MESSAGE CENTER SWITCH OVERHEAD CONSOLE PNK WIRE POWER WINDOWS SYSTEM RADIO REAR AUXILIARY A/C CONTROL ILLUMINATION REAR RADIO CONTROLLER REAR SEAT ENTERTAILMENT MODULE RIGHT DOOR LOCK SWITCH SOUND SYSTEM/ POWER WINDOWS SYSTEM PNK WIRE TRACTION ASSIST/ PARKING AID DISABLE SWITCH
