Passive anti-theft circuit for Ford Windstar I (1994-2003)
Passive anti-theft circuit
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/WHT WIRE
FUSE 20
GRY/ORG WIRE
HOT IN RUN OR START
LT GRN WIRE
LT GRN/YEL WIRE
PASSIVE ANTI-THEFT TRANSCEIVER (ON STEERING COLUMN)
POWERTRAIN CONTROL MODULE (BEHIND RIGHT SIDE OF DASH, THROUGH FIREWALL)
RED WIRE
STARTER INTERRUPT RELAY
WHT WIRE
WHT/LT GRN WIRE
