Manual a/c circuit, rear a/c for Ford Windstar I (1994-2003)

1 2 3 4 5 6 7 8 REAR ELEC MOD SIG OUT 1 2 3 4 5 6 7 8 REAR ELEC MODULE SIG OUT AUXILIARY A/C BLEND DOOR ACTUATOR (LEFT OF REAR SEAT) AUXILIARY A/C BLOWER RELAY MODULE AUXILIARY A/C MODE DOOR ACTUATOR (LEFT OF REAR SEAT) AUXILIARY BLOWER MOTOR (BEHIND PANEL, LEFT OF REAR SEAT) AUXILIARY BLOWER MOTOR RELAY AUXILIARY BLOWER MOTOR RESISTOR ASSEMBLY (BEHIND PANEL, LEFT OF REAR SEAT) AUXILIARY BLOWER SPEED RELAY 1 AUXILIARY BLOWER SPEED RELAY 2 BLK WIRE BLK/LT BLU WIRE BLK/ORG WIRE CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM FUSE 11 FUSE 23 FUSE 8 GRY/ORG WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES IGNITION LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/RED WIRE ORG/ WIRE ORG/RED WIRE PNK/BLK WIRE PNK/LT BLU WIRE PNK/LT GRN WIRE PNK/YEL WIRE REAR AUXILIARY A/C CONTROL REAR ELECTRONIC MODULE (REM) (AT RIGHT REAR QUARTER PANEL) RED WIRE SWITCHED SYSTEM POWER RELAY 4 TAN WIRE TAN/LT GRN WIRE TAN/ORG WIRE TAN/RED WIRE TAN/YEL WIRE WHT WIRE WHT/LT BLU WIRE WHT/RED WIRE YEL WIRE YEL/LT BLU WIRE YEL/RED WIRE
