Ford Windstar I (1994-2003) rear wash switch Wiring diagram
This page shows the only wiring diagram for the component.rear wash switch, which is found in the car Ford Windstar I (1994-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear wash switch (1 of 1)
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPARTMENT)
BLK WIRE
BRN/WHT WIRE
DK GRN/VIO WIRE
FRONT ELECTRONIC MODULE (BELOW LEFT SIDE OF DASH)
FUSE 7
HOT AT ALL TIMES
INT 2 INT 1 OFF
LIFTGATE WASHER PUMP MOTOR (IN WASHER FLUID RESERVOIR)
LIFTGATE WIPER
LIFTGATE WIPER MOTOR (INSIDE LIFTGATE)
LT BLU/WHT WIRE
MULTIFUNCTION SWITCH
REAR WASH SWITCH
RED WIRE
REF GROUND
RELAY
VIO/LT BLU WIRE
WHT/LT GRN WIRE
WIPER INPUT
