Ford Windstar I (1994-2003) low speed fan ctrl Wiring diagram
This page shows the only wiring diagram for the component.low speed fan ctrl, which is found in the car Ford Windstar I (1994-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low speed fan ctrl (1 of 1)
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPARTMENT)
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPARTMENT) FUSE 107
BLK WIRE
BLK/ORG WIRE
COOLING FAN DROPPING RESISTOR (ON LOWER LEFT FRONT OF ENGINE COMPARTMENT)
DK BLU WIRE
ENGINE COOLING FAN MOTOR HIGH SPEED RELAY
ENGINE COOLING FAN MOTOR LOW SPEED RELAY
FUSE 20
HIGH SPEED FAN CTRL
HOT AT ALL TIMES
HOT IN START OR RUN
LEFT ELECTRIC COOLING FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR)
LOW SPEED FAN CTRL
LT GRN WIRE
LT GRN/VIO WIRE
NCA WIRE
ORG/ WIRE
ORG/LT GRN WIRE
POWERTRAIN CONTROL MODULE (PCM) (BEHIND RIGHT SIDE OF DASH, THROUGH FIREWALL)
RED WIRE
RED/ORG WIRE
RIGHT ELECTRIC COOLING FAN MOTOR (BEHIND RIGHT SIDE OF RADIATOR)
VIO WIRE
Go to component -> Cooling fan circuit -> LOW SPEED FAN CTRL
