Ford Windstar I (1994-2003) fuse 5 Wiring diagrams

A/C CLUTCH RELAY BATTERY BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) TO FUSE 102 (DIAGRAM BLK WIRE BRN WIRE BRN/WHT WIRE DK GRN WIRE ELECTRONIC BRAKE SWITCH CONNECTOR FROM FUSE 105 (DIAGRAM 1 OF 4) FROM FUSE 6 (DIAGRAM 1 OF 4) FRONT ELECTRONIC MODULE FUEL PUMP RELAY FUSE 1 FUSE 105 FUSE 107 FUSE 112 FUSE 113 FUSE 13 FUSE 2 FUSE 3 FUSE 4 FUSE 5 FUSE 6 FUSE 7 FUSIBLE LINK GENERATOR GRY WIRE HORN RELAY LIFTGATE WASHER PUMP MOTOR LIFTGATE WIPER MOTOR LIFTGATE WIPER RELAY LT BLU WIRE LT GRN WIRE LT GRN/VIO WIRE ORG/ WIRE PCM POWER RELAY POWERTRAIN CONTROL MODULE RED WIRE STARTER INTERRUPT RELAY STARTER MOTOR SOLENOID TO FUSE 2 (DIAGRAM 1 OF 4) TO FUSE 7 (DIAGRAM 1 OF 4) VIO WIRE WHT WIRE WINDSHIELD WASHER PUMP MOTOR WINDSHIELD WIPER MOTOR WINDSHIELD WIPER ON/ OFF RELAY WINDSHIELD WIPER SPEED RELAY YEL WIRE

A/C CLUTCH CYCLING PRESSURE SWITCH ANTI-LOCK BRAKE CONTROL MODULE AUTOLAMP SENSOR AUXILIARY A/C BLOWER RELAY MODULE (IN CENTRAL JUNCTION BOX) AUXILIARY BLOWER SPEED RELAY 1 AUXILIARY BLOWER SPEED RELAY 2 BATTERY JUNCTION BOX BLK WIRE BLK/LT GRN WIRE BRAKE PEDAL POSITION SWITCH BRAKE PRESSURE SWITCH BRN WIRE CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) CLIMATE CONTROL SWITCH ASSEMBLY BLEND DOOR ACTUATOR CONSOLE POWER POINT 1 I/P POWER POINT DATA LINK CONNECTOR DIGITAL TRANSMISSION RANGE SENSOR DK BLU WIRE DK GRN WIRE ELECTRONIC DAY/NIGHT MIRROR FROM FUSE 115 (DIAGRAM 2 OF 4) FROM FUSE 119 (DIAGRAM 2 OF 4) FROM FUSE 6, (DIAGRAM 3 OF 4) FROM IGNITION FROM IGNITION SWITCH STA (DIAGRAM 2 OF 4) FRONT ELECTRONIC MODULE FUSE 10 REAR WINDOW DEFROST RELAY FUSE 11 FUSE 14 FUSE 16 FUSE 17 FUSE 19 FUSE 23 FUSE 25 FUSE 26 FUSE 28 FUSE 5 FUSE 6 FUSE 9 GRN WIRE I/P CIGAR LIGHTER INSTRUMENT CLUSTER INSTRUMENT CLUSTER PCM DIODE LEFT POWER SLIDING DOOR MODULE LT BLU WIRE LT GRN WIRE LT GRN/VIO WIRE NCA WIRE ORG/ WIRE OVERHEAD CONSOLE PNK 1 PNK 1 WIRE PNK 15 WIRE PNK 7 WIRE PNK WIRE RADIO REAR ELECTRONIC MODULE REAR POWER POINT REAR RADIO CONTROL REAR SEAT ENTERTAINMENT MODULE REMOTE KEYLESS ENTRY MODULE RADIO RED WIRE RED/BLK WIRE RESTRAINT CONTROL MODULE RIGHT POWER SLIDING DOOR MODULE SHIFT LOCK ACTUATOR INSTRUMENT CLUSTER SPEED CONTROL SERVO TAN/BLK WIRE TO CENTRAL JUNCTION BOX (DIAGRAM 3 OF 4) TRANSMISSION CONTROL SWITCH COMPASS MODULE VIO WIRE W/ REAR SEAT ENTERTAINMENT W/O REAR SEAT ENTERTAINMENT WHT WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE

A/C SYSTEM ANTI-THEFT IND PSP SWITCH ANTI-THEFT SYSTEM BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) FUSE 19 BLK WIRE BLK/PNK WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/PNK WIRE CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) CHARGING SYSTEM COOLING FANS SYSTEM DATA LINK (-) DATA LINK (+) RX SIG TX SIG DATA LINK CONNECTOR (DLC) (BELOW DASH, ON RIGHT OF STEERING COLUMN) DIGITAL TRANSMISSION RANGE (DTR) SENSOR (ON TOP OF TRANSAXLE) DK BLU WIRE DK BLU/LT GRN WIRE DK GRN WIRE DK GRN/WHT WIRE DK GRN/YEL WIRE DLC (PWR SPLY) FUEL PUMP RELAY FUSE 1 FUSE 20 FUSE 5 FUSE 9 GRY WIRE GRY/ORG WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT IN RUN OR START IGN COIL 1 DRV SHIFT SOL A LOW SPD FAN IGNITION COIL (ON TOP RIGHT REAR OF ENGINE) IMRC SOL LT BLU WIRE LT BLU/BLK WIRE LT BLU/ORG WIRE LT GRN/RED WIRE LT GRN/VIO WIRE LT GRN/YEL WIRE MAF SIG RTN TRANS FL TEMP ECT SENS IN IAT SENS FUEL PUMP MON A/C SIG IMRC SOL ORG/ WIRE ORG/BLK WIRE ORG/WHT WIRE ORG/YEL WIRE PCM DIODE PCM POWER RELAY PNK/LT BLU WIRE PNK/WHT WIRE POWERTRAIN CONTROL MODULE (PCM) (BEHIND RIGHT SIDE OF DASH, THROUGH FIREWALL) PRIMARY PWR FEED CKP IN (+) CKP IN (-) PWR GND PWR GND IGN COIL 2 DRV RED WIRE RED/LT BLU WIRE RED/LT GRN WIRE RED/PNK WIRE RED/YEL WIRE SECONDARY STARTER RELAY GENERATOR HIGH SPD FAN EGR VAC REG STARTING/ CHARGING SYSTEM TAN/LT BLU WIRE TAN/ORG WIRE TO DTR SENSOR (DIAGRAM 4 OF 4) TO SPARK PLUGS TSS SENS VIO WIRE VIO/ORG WIRE WHT/BLK WIRE WHT/LT GRN WIRE YEL WIRE YEL/LT GRN WIRE
