Ford Windstar I (1994-2003) fuse 106 Wiring diagrams
This page contains all the electrical diagrams for the component. fuse 106, in which he is found in the car Ford Windstar I (1994-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fuse 106 (1 of 3)
ACCESSORY DELAY RELAY
ADJUSTABLE PEDAL SWITCH
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) FUSE 18
CLIMATE CONTROL SWITCH ASSEMBLY
DK BLU/LT GRN WIRE
FRONT ELECTRONIC MODULE (BELOW LEFT SIDE OF DASH)
FUSE 106
HOT AT ALL TIMES
INSTRUMENT CLUSTER
KICK PANEL)
LT BLU WIRE
LT BLU/BLK WIRE
LT BLU/WHT WIRE
LT GRN/RED WIRE
MAIN LIGHT SWITCH
MASTER WINDOW/ DOOR LOCK/UNLOCK SWITCH
MESSAGE CENTER SWITCH
OVERHEAD CONSOLE
PNK WIRE
POWER WINDOWS SYSTEM
RADIO
REAR AUXILIARY A/C CONTROL ILLUMINATION
REAR RADIO CONTROLLER
REAR SEAT ENTERTAILMENT MODULE
RIGHT DOOR LOCK SWITCH
SOUND SYSTEM/ POWER WINDOWS SYSTEM PNK WIRE
TRACTION ASSIST/ PARKING AID DISABLE SWITCH
Go to component -> Instrument illumination circuit -> FUSE 106
Wiring diagram fuse 106 (2 of 3)
ACCESSORY DELAY RELAY
ADJUSTABLE PEDAL SWITCH
ANTI-LOCK BRAKE CONTROL MODULE
AUXILIARY BLOWER MOTOR RELAY
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BRN WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) FUSE 15
CONSOLE POWER POINT 2
DK BLU WIRE
DK GRN WIRE
EXTERIOR REAR VIEW MIRROR SWITCH
FROM
FROM FUSE 112 (DIAGRAM 1 OF 4)
FROM FUSE 117 (DIAGRAM 2 OF 4)
FROM FUSE 122 (DIAGRAM 2 OF 4)
FRONT BLOWER MOTOR RELAY
FUSE 101
FUSE 102
FUSE 104
FUSE 106
FUSE 110
FUSE 111
FUSE 115
FUSE 116
FUSE 117
FUSE 118
FUSE 119 FUSE 121
FUSE 120
FUSE 122
FUSE 3
IGNITION SWITCH
LEFT POWER LUMBAR SWITCH
LEFT POWER SLIDING DOOR MODULE
LEFT SEAT CONTROL SWITCH
LOCK OFF
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PNK 9 WIRE
PNK WIRE
REAR WINDOW DEFROST RELAY
RED WIRE
RIGHT POWER LUMBAR SWITCH
RIGHT POWER SLIDING DOOR MODULE
RIGHT SEAT CONTROL SWITCH
RUN WIRE
TAN WIRE
TO FUSE 10 (DIAGRAM 3 OF 4)
TO FUSE 106 (DIAGRAM 2 OF 4)
TO FUSE 111 (DIAGRAM 2 OF 4)
TO FUSE 17 (DIAGRAM 3 OF 4)
TO FUSE 25 (DIAGRAM 3 OF 4)
TO FUSE 26 (DIAGRAM 3 OF 4)
TO FUSE 28 (DIAGRAM 3 OF 4)
TO FUSE 5 (DIAGRAM 3 OF 4)
TO FUSE 9 (DIAGRAM 3 OF 4)
TO FUSE 9 (DIAGRAM 4 OF 4)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> FUSE 106
Wiring diagram fuse 106 (3 of 3)
ACCESSORY DELAY RELAY
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPARTMENT)
BLK WIRE
BLK/ORG WIRE
BLK/YEL WIRE
BRN WIRE
BRN/YEL WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DK BLU WIRE
DN UP
FRONT ELECTRONIC MODULE (BELOW LEFT SIDE OF DASH)
FUSE 106
FUSE 18
HOT AT ALL TIMES
LEFT POWER QUARTER WINDOW MOTOR RIGHT POWER QUARTER WINDOW MOTOR
LEFT POWER WINDOW
LEFT POWER WINDOW MOTOR
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
MASTER WINDOW/ DOOR LOCK/ UNLOCK SWITCH
ONE- TOUCH DOWN
ORG/ WIRE
ORG/YEL WIRE
PNK SOUND SYSTEMS WIRE
PNK WIRE
RED WIRE
RED/LT GRN WIRE
RIGHT POWER WINDOW
RIGHT POWER WINDOW MOTOR
RIGHT POWER WINDOW SWITCH
TAN WIRE
UP DN LEFT FLIP WINDOW RIGHT FLIP WINDOW
WHT WIRE
YEL WIRE
Go to component -> Power window circuit -> FUSE 106
