Ford Windstar I (1994-2003) climate control switch assembly i/p power point Wiring diagram
This page shows the only wiring diagram for the component.climate control switch assembly i/p power point, which is found in the car Ford Windstar I (1994-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram climate control switch assembly i/p power point (1 of 1)
A/C CLUTCH FIELD COIL
ADJUSTABLE PEDAL SWITCH
ANTI-LOCK BRAKE CONTROL MODULE
ANTI-THEFT HOOD SWITCH
BATTERY
BATTERY JUNCTION BOX
BLK WIRE
BLOWER MOTOR RESISTOR BLEND DOOR ACTUATOR MAIN LIGHT SWITCH
BRAKE FLUID WARNING SWITCH
CLIMATE CONTROL SWITCH ASSEMBLY I/P POWER POINT
CONSOLE POWER POINT 1
CONSOLE POWER POINT 2
COOLING FAN MOTOR
CRANKSHAFT POSITION SENSOR SHIELD
DATA LINK CONN
DUAL PITCH HORN
FUEL PUMP/ FUEL GAUGE SENDER
GLOVE BOX LAMP MESSAGE CENTER SWITCH
I/P CIGAR LIGHTER
INTAKE MANIFOLD RUNNER CONTROL MONITOR
LEFT ELECTRIC
LIFTGATE WIPER RELAY PCM POWER RELAY
MASS AIRFLOW SENSOR
NCA WIRE
NOT USED
PANEL)
PASSIVE ANTI-THEFT SYSTEM TRANSCEIVER MODULE
POWERTRAIN CONTROL MODULE
RADIO
REAR ELECTRONIC MODULE
REAR SEAT ENTER- TAINMENT MODULE
RIGHT ELECTRIC
RIGHT POWER SLIDING DOOR MODULE
SHIFT LOCK ACT- UATOR BLOWER MOTOR SWITCH
SPEED CONTROL DELETE CAP
SPEED CONTROL SERVO
SWITCH
TRACTION ASSIST/ PARKING AID DISABLE SWITCH
VIDEO CASSETTE PLAYER
W/ SPEED CONTROL
W/O SPEED CONTROL
W/REAR SEAT ENTERTAINMENT
WASHER FLUID LEVEL SWITCH
WHT WIRE
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (1 of 3) -> CLIMATE CONTROL SWITCH ASSEMBLY I/P POWER POINT
