Power mirrors circuit for Ford Transit VII (2006-2013)
Power mirrors circuit
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DEFOGGER SYSTEM
DOWN UP
DRIVER SIDE EXTERIOR REAR VIEW MIRROR (DRIVER'S DOOR)
EXTERIOR REAR VIEW MIRROR SWITCH
FUSE 131
GRN WIRE
HOT AT ALL TIMES
LEFT RIGHT
MIRROR SELECT
ORG/ WIRE
ORG/YEL WIRE
PASSENGER SIDE EXTERIOR REAR VIEW MIRROR (PASSENGER'S DOOR)
RED WIRE
VIO WIRE
WHT WIRE
YEL WIRE
