Anti-lock brakes circuit, with dynamic stability control for Ford Transit VII (2006-2013)

23 24 7 HS CAN+ HS CAN- BRAKE WARNING 4 3 2 1 VBAT HS CAN- HS CAN+ GND 46 13 43 59 BPS BPP HS CAN- HS CAN+ ABS TEST CONNECTOR (LEFT REAR OF ENGINE COMPT) ANTI-LOCK BRAKE SYSTEM (ABS) CONTROL MODULE (LEFT REAR OF ENGINE COMPT) BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRAKE PEDAL POSITION SWITCH (BRAKE PEDAL SUPPORT BRACKET) BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) CLUS GND CLUS PWR COMPUTER DATA LINES SYSTEM FUSE FUSE 161 FUSE 26 GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/RED WIRE GRY/VIO WIRE HOT AT ALL TIMES BATTERY JUNCTION BOX (BJB) (LEFT REAR CORNER OF ENGINE COMPT) HOT IN START OR RUN HOT W/ PCM POWER RELAY ENERGIZED HS CAN + HS CAN - HS CAN YAW - HS CAN YAW + IGN INSTRUMENT CLUSTER (IC) LEFT FRONT WHEEL SPEED SENSOR (LEFT FRONT WHEEL HUB) LEFT REAR WHEEL SPEED SENSOR (LEFT REAR WHEEL HUB) LF WHL SPD+ LF WHL SPD- GND LR WHL SPD LR WHL SPD MICROPHONE NCA WIRE ORG/ WIRE PARK BRAKE SWITCH (CENTER CONSOLE) POWERTRAIN CONTROL MODULE RED WIRE RIGHT FRONT WHEEL SPEED SENSOR (RIGHT FRONT WHEEL HUB) RIGHT REAR WHEEL SPEED SENSOR (RIGHT REAR WHEEL HUB) RR WHL SPD RR WHL SPD SOLID STATE STABILITY CONTROL SENSOR MODULE (CENTER CONSOLE) STEERING ANGLE SENSOR MODULE (SASM) (STEERING COLUMN) VBAT RF WHL SPD- RF WHL SPD+ WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE
