Ford Transit VII (2006-2013) rr int sw wiring diagram
This page shows the only wiring diagram for the component.rr int sw, which is found in the car Ford Transit VII (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
rr int sw wiring diagram (1 of 1)
1) HIGH 2) LOW 3) INTERMITTENT 4) OFF 5) SINGLE PASS
14 7 FR INT DATA 3 FR INT DATA 2
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
FLUID RESERVOIR)
FR HI SPEED SW
FR INT DATA 1
FR INT/AUTO SW
FR WASH SW
FR WIPER HI
FR WIPER LO
FR WIPER PRK POS
FRONT WIPER
FRONT WIPER RELAY
FUSE 146
FUSE 180
GENERIC ELECTRONIC MODULE (GEM) (LOWER LEFT SIDE OF DASH)
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
HOT IN RUN AND START
HOT IN RUN OR START
IGN FR WIPER
LEFT REAR WIPER MOTOR ASSEMBLY (IN LEFT REAR DOOR)
NCA WIRE
OFF
REAR WASHER
REAR WIPER
RIGHT REAR WIPER MOTOR ASSEMBLY (IN RIGHT REAR DOOR)
RR INT SW
RR WASH SW
RR WIPER OUT
RR WIPER SPLY
TWO-WAY WASHER PUMP MOTOR (IN WASHER
VARIABLE INTERM
W/ REAR WIPERS
W/O REAR WIPERS
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WINDSHIELD WIPER MOTOR
WIPER/WASHER SWITCH
YEL/BLK WIRE
Go to component -> Wiper/washer circuit -> RR INT SW
