Ford Transit VII (2006-2013) right front door ajar Wiring diagram
This page shows the only wiring diagram for the component.right front door ajar, which is found in the car Ford Transit VII (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front door ajar (1 of 1)
19 17 18 RF DR AJAR REAR DR AJAR LF DR AJAR
BATT SAVER OUT
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DRIVER SIDE DOOR LOCK
FRONT INTERIOR/ MAP LAMPS ASSEMBLY ON
FUSE
GENERIC ELECTRONIC MODULE (GEM) (LOWER LEFT SIDE OF DASH)
HOT AT ALL TIMES
INT LAMPS RELAY
INTERIOR LAMPS RELAY
LEFT FRONT DOOR AJAR
LEFT SLIDING DOOR AJAR
LOCK UNIT (PASSENGER'S DOOR)
ON ON OFF COURTESY
ORG/ WIRE
ORG/BLU WIRE
PASSENGER SIDE DOOR
REAR DOOR DOOR LOCK
REAR DOORS DOOR AJAR
REAR INTERIOR LAMPS 1
REAR INTERIOR LAMPS 2
RIGHT FRONT DOOR AJAR
RIGHT SLIDING DOOR AJAR
SLIDING DR AJAR
SWITCH (BASE OF LEFT "C" PILLAR)
SWITCH (BASE OF RIGHT "C" PILLAR)
SWITCH (LEFT KICK PANEL)
SWITCH (RIGHT "D" PILLAR)
SWITCH (RIGHT KICK PANEL)
UNIT (DRIVER'S DOOR)
UNIT)
W/ MANUAL DOOR LOCKS
W/ POWER DOOR LOCKS
Go to component -> Courtesy lamps circuit -> RIGHT FRONT DOOR AJAR
