Ford Transit VII (2006-2013) generator rc ig Wiring diagram
This page shows the only wiring diagram for the component.generator rc ig, which is found in the car Ford Transit VII (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram generator rc ig (1 of 1)
BATTERY
BATTERY JUNCTION BOX (BJB) (LEFT REAR CORNER OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
COMPUTER DATA LINES SYSTEM
FUSE 6
GENCOM
GENERATOR RC IG
GENMON
GRY/RED WIRE
GRY/VIO WIRE
HS CAN+
INSTRUMENT CLUSTER (IC)
MIDI
ORG/ WIRE
POWERTRAIN CONTROL MODULE (PCM) (REAR OF ENGINE)
RED WIRE
RED/YEL WIRE
STARTING CIRCUIT
VIO WIRE
