Car Wiring Diagrams for Charging circuit for Ford Transit T8 (2023-2024)

3.5L FLEX ACTIVE GRILLE SHUTTER AUXILIARY BATTERY BATTERY BATTERY JUNCTION BOX (BJB) BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM ENGINE CONTROLS SYSTEM FUSE 1 FUSE 12 FUSE 2 FUSE 9 GRN/VIO WIRE GRN/WHT WIRE GRY/RED WIRE HIGH CURRENT BATTERY JUNCTION BOX (BJB) INLINE FUSE 1 INLINE FUSE 2 NCA WIRE POWERTRAIN CONTROL MODULE (PCM) RED WIRE S172 (3.5L TURBO) SIG RTN STARTER MOTOR VREF W/ DUAL BATTERY W/ SMART REGEN CHARGE WHT WIRE WHT/GRN WIRE YEL/VIO WIRE

AUXILIARY BATTERY RELAY AUXILIARY JUNCTION BOX (AJB) B+ CONV SENSE BATTERY MONITORING SENSOR BEACON SW SRC GND BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE BODY CONTROL MODULE (BCM) BRN/WHT WIRE BRN/YEL WIRE COIL DISENGAGE COIL ENGAGE COIL ENGAGE GND COIL DISENGAGE GND COMPUTER DATA LINES SYSTEM ENGINE RUN ENGINE RUN OUT FORCE CLOSE RELAY SWITCH FORCE OPEN RELAY SWITCH FUSE 48 FUSE 52 GENERATOR GENERATOR CURRENT SENSOR GRN/BLU WIRE GRN/VIO WIRE GRN/WHT WIRE GRY/RED WIRE GRY/VIO WIRE GRY/YEL WIRE HOT W/ RUN/START RELAY 2 ENERGIZED INSTRUMENT PANEL CLUSTER (IPC) LIN 3 LOAD SHED GND LOAD SHED GND VEHICLE MICRO - NCA WIRE ON BATTERY) ORG/BLK WIRE ORG/GRN WIRE ORG/GRY WIRE ORG/YEL WIRE POWER DISTRIBUTION SYSTEM PWR ISOLATION WARNING RED WIRE RIGHT END OF DASH) RPM SPEED 1 RPM SPEED 2 SRC INHIBIT INPUT TEMP SENSE 1 TEMP SENSE 2 TO AUX TEMP SENSOR UPFITTER CONTROL MODULE (UCM) (W/ SMART REGEN CHARGE) (UNDER DRIVER'S SEAT) VBATT VPWR W/ SMART REGEN CHARGE WHT WIRE WHT/GRN WIRE YEL/VIO WIRE
