Car Wiring Diagrams for Heated seats circuit for Ford Transit T8 (2023-2024)

AUXILIARY JUNCTION BOX (AJB) BLK WIRE BLK/GRY WIRE BLU WIRE DRIVER SIDE FRONT SEAT BACK HEATER DRIVER SIDE FRONT SEAT CUSHION HEATER DRV HEAT SEAT NTC + DRV HEAT SEAT PWR FUSE 64 FUSE 65 GRY WIRE GRY/BLU WIRE GRY/YEL WIRE HOT W/ RUN/START RELAY 1 ENERGIZED HVAC MODULE (CENTER OF DASH) NCA WIRE PASS HEAT SEAT NTC + PASS HEAT SEAT PWR PASSENGER SIDE FRONT SEAT BACK HEATER PASSENGER SIDE FRONT SEAT CUSHION HEATER RTN VIO/WHT WIRE VPWR WHT/BLU WIRE YEL WIRE YEL/GRN WIRE
