Instrument illumination circuit for Ford Transit T8 (2023-2024)

AUXILIARY JUNCTION BOX (AJB) BLK WIRE BLK/GRY WIRE BLU WIRE BODY CONTROL MODULE (BCM) COMPUTER DATA LINES SYSTEM DRIVER DOOR LOCK SWITCH ELECTRONIC PARK BRAKE SWITCH EXCEPT ELECTRIC FUSE 37 FUSE 77 GRN/VIO WIRE GRY WIRE HAZARD SWITCH HEADLAMP SWITCH HOT AT ALL TIMES IP/SWITCH ILLUM (FET) LEFT MULTI FUNCTION SWITCH LIN 9 MICRO - PUSH BUTTON START IGNITION SWITCH RIGHT MULTI- FUNCTION SWITCH SELECTOR LEVER ASSEMBLY VBATT VIO WIRE VIO/GRY WIRE W/ AUXILIARY FUSE PANEL WHT WIRE YEL/RED WIRE

AUXILIARY SWITCH BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/YEL WIRE COMPUTER DATA LINES SYSTEM FRONT INTERIOR LAMP GRN/ORG WIRE GRY/BLU WIRE HORN SWITCH INTERIOR LAMP SWITCH LEFT STEERING WHEEL SWITCH MULTI- FUNCTION SWITCH NCA WIRE PASSENGER AIR BAG DEACTIVATION (PAD) INDICATOR PASSENGER DOOR LOCK SWITCH REAR HVAC MODULE RIGHT END OF DASH) RIGHT STEERING WHEEL SWITCH STEERING COLUMN CONTROL MODULE (SCCM) VIO/GRY WIRE W/ AUXILIARY FUSE PANEL W/ LOW ROOF W/O LOW ROOF
