Car Wiring Diagrams for Trailer/camper adapter circuit for Ford Transit T8 (2023-2024)

3.5L FLEX AUXILIARY JUNCTION BOX (AJB) BACKUP LAMPS CIRCUIT BATTERY JUNCTION BOX (BJB) BLK/GRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (BCM) BRN WIRE COMPUTER DATA LINES SYSTEM ELECTRIC FUSE 10 FUSE 37 FUSE 50 FUSE 55 FUSE 71 FUSE 73 GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/YEL WIRE HIGH CURRENT BATTERY JUNCTION BOX (BJB) HOT AT ALL TIMES HOT W/ RUN/START RELAY 2 ENERGIZED IGN LH STOP/TURN LAMP MICRO - MS CAN + PARK LAMPS PRK/ LP RED WIRE RH STOP/TURN LAMP RIGHT END OF DASH) TBCM OUTPUT TRAILER BRAKE CONTROL MODULE TRAILER TOW CONNECTOR TRAILER TOW DETECTION TRAILER TOW MODULE (BASE OF LEFT "B" PILLAR) TRAILER TOW PARK LAMP RELAY VBATT VIO/GRN WIRE VIO/ORG WIRE VPWR WHT WIRE YEL WIRE YEL/RED WIRE
