Wiring diagram rol sensor in (1 of 2)
AUTO PARK
BLK/VIO WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
COMPUTER DATA LINES SYSTEM
FAPA SENSOR LH IN
FAPA SENSOR RH IN
FIL SENSOR IN
FIR SENSOR IN
FOL SENSOR IN
FOR SENSOR IN
FUSE 36
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/ORG WIRE
HOT W/ RUN/START RELAY ENERGIZED
LEFT FRONT ACTIVE PARK ASSIST SENSOR
LEFT FRONT INNER PARKING AID SENSOR
LEFT FRONT OUTER PARKING AID SENSOR
ORG/ WIRE
PARKING AID INDICATION LED
PARKING AID MODULE (PAM) (LEFT SIDE OF DASH)
PARKING AID SWITCH
RAPA SENSOR LH IN
RAPA SENSOR RH IN
RIGHT FRONT ACTIVE PARK ASSIST SENSOR
RIGHT FRONT INNER PARKING AID SENSOR
RIGHT FRONT OUTER PARKING AID SENSOR
RIL SENSOR IN
RIR SENSOR IN
ROL SENSOR IN
ROR SENSOR IN
SENSOR GND
SENSOR PWR
SOLID STATE
VIO/GRY WIRE
VPWR
W/ SYNC 4
W/O SYNC 4
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Parking assistant circuit, early production w/ automated parking aid (1 of 2) -> ROL SENSOR IN
Wiring diagram rol sensor in (2 of 2)
