Ford Transit T8 (2023-2024) power folding mirror relay Wiring diagrams
This page contains all the electrical diagrams for the component. power folding mirror relay, in which he is found in the car Ford Transit T8 (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
power folding mirror relay wiring diagram (1 of 3)
ALL WHEEL DRIVE (AWD) RELAY
AUXILIARY JUNCTION BOX (AJB)
BATTERY ENERGY CONTROL MODULE (BECM)
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR RELAY
CHARGE PORT
CHASSIS CAB
CLOCKSPRING
ELECTRIC
EXCEPT ELECTRIC
FUEL PUMP CONTROL MODULE
GRN WIRE
HAPTIC FEEDBACK LANE DEPARTURE WARNING
HEADLAMP SWITCH
HIGH CURRENT BATTERY JUNCTION BOX (BJB) LOAD SHED RELAY
HIGH MOUNTED STOP LAMP
LEFT HID RELAY
LEFT REAR LAMP ASSEMBLY
LICENSE PLATE LAMP
NCA WIRE
OBGI RELAY
PASSIVE ANTI-THEFT SYSTEM (PATS) TRANSCEIVER
POWER FOLDING MIRROR RELAY
PUSH BUTTON START IGNITION SWITCH
REAR HEATER BLOWER RELAY
RIGHT END OF DASH)
RIGHT HID RELAY
RIGHT REAR LAMP ASSEMBLY
SECONDARY ON-BOARD DIAGNOSTIC CONTROL MODULE A (SOBDM)
STEERING COLUMN CONTROL MODULE (SCCM)
STEERING COLUMN LOCK RELAY
TRAILER TOW REVERSING LAMP RELAY
UPFITTER RELAY 6
VIO WIRE
WHT WIRE
Go to component -> Ground distribution circuit (5 of 11) -> POWER FOLDING MIRROR RELAY
power folding mirror relay wiring diagram (2 of 3)
3.5L FLEX
AIR CONDITIONING (A/C) CLUTCH RELAY
ALL WHEEL DRIVE (AWD) RELAY
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
AUXILIARY RELAY BOX
BATTERY CHARGER CONTROL MODULE (BCCM)
BATTERY JUNCTION BOX (BCMC) (ELECTRIC)
BATTERY JUNCTION BOX (BJB)
BLOWER MOTOR RELAY
BLU WIRE
BLU/GRY WIRE
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/YEL WIRE
CONTACTOR RELAY
COOLING FAN RELAY 1
COOLING FAN RELAY 2
ELECTRIC
EXCEPT ELECTRIC
FROM AUXILIARY JUNCTION BOX (AJB) (DIAGRAM 3 OF 9)
FROM HIGH CURRENT BATTERY JUNCTION BOX (BJB) (DIAGRAM 2 OF 9)
FUEL PUMP RELAY
FUSE 1
FUSE 22
FUSE 23
FUSE 26
FUSE 32
FUSE 33
FUSE 36
FUSE 39
FUSE 40
FUSE 41
FUSE 44
FUSE 52
FUSE 53
FUSE 55
FUSE 7
GRN/RED WIRE
GRY WIRE
GRY/RED WIRE
HORN RELAY
HYBRID PCM POWER RELAY
LEFT HID RELAY
MICRO -
OBGI RELAY
PCM RELAY
POWER FOLDING MIRROR RELAY
POWERTRAIN CONTROL MODULE (PCM)
REAR HEATER BLOWER RELAY
REAR WINDOW DEFROST RELAY
RED WIRE
RIGHT HID RELAY
RUN/
SECONDARY ON-BOARD DIAGNOSTIC CONTROL MODULE A (SOBDM)
SECONDARY ON-BOARD DIAGNOSTIC CONTROL MODULE C (SOBDMC)
STARTER RELAY
STEERING COLUMN LOCK RELAY
TO AUXILIARY JUNCTION BOX (AJB) (DIAGRAM 4 OF 9)
TO FUSE 28 (DIAGRAM 9 OF 9)
TO POWER POINT RELAY 1 (DIAGRAM 6 OF 9)
TRAILER TOW MODULE
TRAILER TOW PARK LAMP RELAY
TRAILER TOW REVERSING LAMP RELAY
VIO/GRN WIRE
VIO/RED WIRE
W/ HID HEADLAMPS
WHT WIRE
WHT/RED WIRE
WIPER MOTOR RELAY
Go to component -> Power distribution circuit (5 of 9) -> POWER FOLDING MIRROR RELAY
power folding mirror relay wiring diagram (3 of 3)
BATTERY JUNCTION BOX (BJB)
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
BRN/WHT WIRE
DEFOGGER SYSTEM
DOWN UP
EXTERIOR MIRROR SWITCH
FUSE 10
FUSE 3
FUSE 52
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
LEFT
LEFT EXTERIOR MIRROR
NAVIGATION SYSTEM
NCA WIRE
POWER DISTRIBUTION SYSTEM
POWER FOLDING MIRROR RELAY
RED WIRE
RIGHT
RIGHT END OF DASH)
RIGHT EXTERIOR MIRROR
RIGHT LEFT
VIO/BRN WIRE
WHT/GRN WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Power mirrors circuit -> POWER FOLDING MIRROR RELAY
