Ford Transit T8 (2023-2024) left side camera wiring diagram
This page shows the only wiring diagram for the component.left side camera, which is found in the car Ford Transit T8 (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left side camera wiring diagram (1 of 1)
AUTO PARK
BLK/BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
COAX
COAX DISPLAY
COMPUTER DATA LINES SYSTEM
DISPLAY
FAPA SENS LH IN
FAPA SENS RH IN
FIL SENS IN
FIR SENS IN
FOL SENS IN
FOR SENS IN
FRONT CAMERA
FRONT PARKING AID CAMERA
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/ORG WIRE
IMAGE PROCESSING MODULE B (IPMB)
LEFT REAR OUTER PARKING AID SENSOR
LEFT SIDE CAMERA
LEFT SIDE PARKING AID CAMERA
LEFT/CENTER REAR INNER PARKING AID SENSOR
ORG/ WIRE
RAPA SENS LH IN
RAPA SENS RH IN
REAR CAMERA
REAR PARKING AID CAMERA
RIGHT REAR INNER PARKING AID SENSOR
RIGHT REAR OUTER PARKING AID SENSOR
RIGHT SIDE CAMERA
RIGHT SIDE PARKING AID CAMERA
RIL SENS IN
RIR SENS IN
ROL SENS IN
ROR SENS IN
SENS GND
SENS PWR
SYNC MODULE (APIM)
VIO/GRY WIRE
VPWR
W/ ACTIVE PARKING AID
W/ CARGO VAN
W/ REAR PARKING AID CAMERA
W/O CARGO VAN
W/O REAR PARKING AID CAMERA
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Parking assistant circuit, w/o automated parking aid (1 of 2) -> LEFT SIDE CAMERA
