Rear auxiliary a/c circuit for Ford Transit Connect II facelift (2018-2024)

A/C CONTROL SWITCH A/C REQUEST SWITCH BATT + BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLU WIRE BLU/GRN WIRE BLU/GRY WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/BLU WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM EVAPORATOR SENS (+) EVAPORATOR SENS GND EXPAN VALVE FUSE 12 FUSE 2 FUSE 4 FUSE 40 GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRN/VIO WIRE GRY/ORG WIRE HEATING, VENTILATION, AIR CONDITIONING (HVAC) MODULE HIGH CURRENT BATTERY JUNCTION BOX (BJB) HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED IGN ILLUM LEFT REAR AIR DISTRIBUTION DOOR ACTUATOR MODE DOOR A MODE DOOR B MODE DOOR C MODE DOOR D MODE DOOR POWER MS CAN + NCA WIRE PWM PWM 1 REAR AUX CLIMATE I/P REAR AUX CLIMATE O/P REAR AUX HEATER SW REAR BLOWER MOTOR REAR BLOWER MOTOR CONTROL MODULE REAR BLOWER MOTOR RELAY REAR ELECTRIC BOOSTER HEATER REAR EVAPORATOR TEMPERATURE SENSOR REAR HEATING, VENTILATION, AIR CONDITIONING (RHVAC) CONTROL MODULE REAR PTC HEATER CTRL REAR THERMOSTATIC EXPANSION VALVE RIGHT REAR AIR DISTRIBUTION DOOR ACTUATOR TAXI TAXI SW TAXI SW GND TAXI SW LED TEMP DOOR A TEMP DOOR B TEMP DOOR C TEMP DOOR D TEMP DOOR POWER TXV OUT CTRL VBATT VIO/BRN WIRE VIO/GRY WIRE VIO/ORG WIRE VPWR WHT WIRE WHT/BRN WIRE WHT/VIO WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE
