Power windows circuit, w/ door module for Ford Tourneo Connect II (2013-2018)
Power windows circuit, w/ door module (1 of 2)
AUXILIARY JUNCTION BOX
BLK WIRE
BLK/GRN WIRE
BLU/RED WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDM)
DRIVER DOOR WINDOW REGULATOR MOTOR
FUSE 3
FUSE 4
FUSE 6
FUSE 7
GRN/RED WIRE
HALL SENSOR 1
HALL SENSOR 2
HALL SENSOR SPLY
HALL SENSOR SUPPLY
HOT AT ALL TIMES
ILLUMINATION
LIN
MS CAN +
PASSENGER DOOR MODULE (PDM)
PASSENGER DOOR WINDOW CONTROL SWITCH
PASSENGER DOOR WINDOW REGULATOR MOTOR
RED WIRE
RETURN
RIGHT REAR DOOR MODULE
SHORT WHEEL BASE LONG WHEEL BASE
VBATT
VIO/BRN WIRE
WINDOW DOWN
WINDOW UP
YEL/RED WIRE
Power windows circuit, w/ door module (2 of 2)
BLK WIRE
BLK/VIO WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BRN/GRN WIRE
FUSE 60
GRY/BLU WIRE
HALL SENSOR 1
HALL SENSOR 2 HALL SENSOR SPLY
HOT AT ALL TIMES
ILLUMINATION
INTERIOR LIGHT RELAY
LEFT REAR DOOR MODULE
LEFT REAR POWER WINDOW MOTOR
LEFT REAR WINDOW CONTROL SWITCH
LIN
MASTER WINDOW CONTROL SWITCH
MICRO -
RETURN
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR WINDOW CONTROL SWITCH
VBATT
VPWR
WINDOW DOWN
WINDOW UP
