Ford Tourneo Connect II (2013-2018) Cooling fan circuit

ACTIVE GRILLE SHUTTER ACTUATOR BATTERY JUNCTION BOX (BJB) (LEFT REAR CORNER OF ENGINE COMPT) BLK/YEL WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BRN/GRN WIRE CHT COMPUTER DATA LINES SYSTEM CYLINDER HEAD TEMPERATURE (CHT) SENSOR ECT ELECTRONICS ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE (ECT) SENSOR ENGINE COOLING FAN MODULE (ON ENGINE COOLING FAN ASSEMBLY) ENGINE COOLING FAN RELAY FAN CONTROL VARIABLE FCV FUSE 34 FUSE 36 FUSE 8 GRN/WHT WIRE GRY/RED WIRE HIGH CURRENT BATTERY JUNCTION BOX HOT AT ALL TIMES HOT W/ POWERTRAIN CONTROL MODULE HS CAN+ LIN NCA WIRE POWERTRAIN CONTROL MODULE (PCM) PWR GND S122 (EXCEPT 1.6L TURBO) SIG RTN V POWER VIO WIRE VIO/BRN WIRE VIO/GRY WIRE VIO/ORG WIRE WHT WIRE WHT/BLU WIRE YEL WIRE
