Trunk, tailgate, fuel door circuit for Ford Thunderbird XI (2000-2005)
Trunk, tailgate, fuel door circuit
1 2 SCP + SCP -
13 10 VBATT
BATTERY JUNCTION BOX (BJB) (IN LUGGAGE COMPT, NEAR BATTERY)
BLK WIRE
BLK/ORG WIRE
BLK/YEL WIRE
BLU WIRE
BLU/ORG WIRE
COMPUTER DATA LINES SYSTEM
ENERGIZED CENTRAL JUNCTION BOX (CJB) (BEHIND RIGHT KICK PANEL)
FRONT ELECTRONIC MODULE (FEM) (IN LEFT "A" PILLAR)
FUSE 1
FUSE 30
GRY WIRE
GRY/WHT WIRE
HOT WITH
LUGGAGE COMPARTMENT LID RELEASE SOLENOID (ON CENTER REAR OF LUGGAGE COMPT)
LUGGAGE COMPARTMENT LID RELEASE SWITCH (ON CENTER REAR OF LUGGAGE COMPT)
ORG/ WIRE
ORG/BLK WIRE
ORG/WHT WIRE
REAR ELECTRONIC MODULE (REM) (BEHIND SEATS, ON VEHICLE CROSSBEAM)
SCP+
SW GND
WHT WIRE
