Car Wiring Diagrams for Heated seats circuit for Ford Thunderbird XI (2000-2005)

BATTERY JUNCTION BOX (BJB) (IN LUGGAGE COMPT, NEAR BATTERY) BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/WHT WIRE BRN/RED WIRE BRN/YEL WIRE DRIVER SIDE FRONT HEATED SEAT MODULE (UNDER DRIVER SEAT) DRIVER SIDE SEAT HEATER SWITCH FUSE 10 FUSE 11 FUSE 16 GRY WIRE GRY/ORG WIRE HIGH IND OFF HIGH OFF HOT AT ALL TIMES HOT IN RUN CENTRAL JUNCTION BOX (CJB) (BEHIND RIGHT KICK PANEL) ILLUMINATION LEFT FRONT SEAT BACK HEATER LEFT FRONT SEAT CUSHION HEATER LOW IND OFF PASSENGER SIDE FRONT HEATED SEAT MODULE (UNDER PASSENGER SEAT) PASSENGER SIDE SEAT HEATER SWITCH PNK WIRE PNK/BLK WIRE PNK/YEL WIRE RED WIRE RIGHT FRONT SEAT BACK HEATER RIGHT FRONT SEAT CUSHION HEATER WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/GRN WIRE
