Courtesy lamps circuit for Ford Thunderbird XI (2000-2005)

BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/RED WIRE CENTRAL JUNCTION BOX (BEHIND RIGHT KICK PANEL) DRIVER SIDE FRONT DOOR AJAR SWITCH FRONT ELECTRONIC MODULE (IN LEFT ``A" PILLAR) FRONT INTERIOR/ MAP LAMPS ASSEMBLY FUSE 30 FUSE 31 FUSE 4 FUSE 8 GLOVE BOX LAMP) GRN WIRE HIGH MOUNTED STOPLAMP INTERIOR AUXILIARY JUNCTION BOX (UNDER LEFT SIDE OF DASH) LEFT FRONT FOOTWELL LAMP LUGGAGE COMPARTMENT LID AJAR SWITCH (ON CENTER REAR OF LUGGAGE COMPARTMENT) LUGGAGE COMPT LAMP NCA WIRE ORG/ WIRE ORG/BLU WIRE ORG/WHT WIRE PASSENGER SIDE FRONT DOOR AJAR SWITCH RADIO CAPACITOR (UNDER LEFT SIDE OF DASH) REAR ELECTRONIC MODULE (REM) (BEHIND SEATS, ON VEHICLE CROSSBEAM) RED WIRE RED/BLU WIRE RED/YEL WIRE RELAY ENERGIZED RELAY ENERGIZED BATTERY JUNCTION BOX (IN LUGGAGE COMPT, NEAR BATTERY) RIGHT FRONT FOOTWELL LAMP WHT WIRE WHT/BLK WIRE YEL WIRE
