Car Wiring Diagrams for Horn circuit for Ford Thunderbird XI (2000-2005)

BLK WIRE BLK/GRN WIRE BLU WIRE BRN WIRE BRN/RED WIRE CENTRAL JUNCTION BOX (BEHIND RIGHT KICK PANEL) COMPT) 1 2 COMPUTER DATA LINES SYSTEM EARLY PRODUCTION FRONT ELECTRONIC MODULE (FEM) (IN LEFT "A" PILLAR) FUSE 20 GRN WIRE GRY WIRE HORN (ON RIGHT FRONT OF ENGINE HORN RELAY HORN SWITCH HOT AT ALL TIMES INSTRUMENT CLUSTER INTERIOR AUXILIARY JUNCTION BOX (AJB) (UNDER LEFT SIDE OF DASH) LATE PRODUCTION NCA WIRE ORG/ WIRE ORG/BLU WIRE ORG/GRN WIRE RED WIRE RED/BLU WIRE RED/YEL WIRE UNDERHOOD AUXILIARY JUNCTION BOX (AJB) (IN RIGHT FRONT OF ENGINE COMPT) VIO WIRE WHT WIRE
