Ford Thunderbird XI (2000-2005) wiper high/low relay Wiring diagram

This page shows the only wiring diagram for the component.wiper high/low relay, which is found in the car Ford Thunderbird XI (2000-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram wiper high/low relay (1 of 1)

Wiring diagram wiper high/low relay for Ford Thunderbird XI (2000-2005)

Get access

BLK WIRE BRN WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND RIGHT KICK PANEL) FUSE 24 FUSE 26 GRN WIRE HOT AT ALL TIMES HOT IN RUN OR ACC MULTI- FUNCTION SWITCH ORG/ WIRE RED WIRE REST RUN WIRE SOLID STATE UNDERHOOD AUXILIARY JUNCTION BOX (AJB) (IN RIGHT FRONT OF ENGINE COMPT) WASH SWITCH WHT WIRE WINDSHIELD WASHER PUMP MOTOR (ON WINDSHIELD WASHER FLUID RESERVOIR) WINDSHIELD WIPER RELAY WIPER HIGH/LOW RELAY WIPER RUN/PARK RELAY

Go to component: -> Wiper/washer circuit -> WIPER HIGH/LOW RELAY
