Ford Thunderbird XI (2000-2005) transmission fluid temperature sensor Wiring diagram

AUTOMATIC TRANSMISSION AUXILIARY JUNCTION BOX (UNDERHOOD) (IN RIGHT FRONT OF ENGINE COMPT) BLK/ORG WIRE BLU WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE FUSE 5 FUSE 6 GRN/BLK WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE ISS ORG/ WIRE OSS + P,2,1 P,N,1 P,R,2 P,R,N,3/4 PCS A PCS B PCS C POWER POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPT) PRESS CTRL SOL C PRESS CTRL SOL B PRESS CTRL SOL A TCC SOL SHIFT SOL. SHIFT SOL. SIG RTN SS A SS B SS C SS D TCC SOL TFT TRANSMISSION FLUID TEMPERATURE SENSOR TSS WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL/GRN WIRE
