Ford Thunderbird XI (2000-2005) out up Wiring diagram

This page shows the only wiring diagram for the component.out up, which is found in the car Ford Thunderbird XI (2000-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram out up (1 of 1)

Wiring diagram out up for Ford Thunderbird XI (2000-2005)

Get access

BLK WIRE BLU/BLK WIRE BRN WIRE BRN/WHT WIRE CENTRAL JUNCTION BOX (BEHIND RIGHT KICK PANEL) DOWN FUSE 19 (EARLY PRODUCTION) (LATE PRODUCTION) HOT AT ALL TIMES INSTRUMENT CLUSTER ORG/ WIRE OUT UP STEERING COLUMN POSITION MOTOR (ON STEERING COLUMN) STEERING COLUMN POSITION SENSOR (ON STEERING COLUMN) STEERING COLUMN POSITION SWITCH TELESCOPE TILT VIO/BLK WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/VIO WIRE

Go to component: -> Power steering column circuit -> OUT UP
