Ford Thunderbird XI (2000-2005) left right Wiring diagram
This page shows the only wiring diagram for the component.left right, which is found in the car Ford Thunderbird XI (2000-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left right (1 of 1)
BLK WIRE
BLK/ORG WIRE
BLK/YEL WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND RIGHT KICK PANEL)
EXTERIOR REAR VIEW MIRROR SWITCH
FUSE
HOT AT ALL TIMES
LEFT EXTERIOR REAR VIEW MIRROR
LEFT RIGHT
MIRROR SELECT
NCA WIRE
ORG/YEL WIRE
RED WIRE
RIGHT EXTERIOR REAR VIEW MIRROR
UP DOWN
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> LEFT RIGHT
