Ford Thunderbird XI (2000-2005) left front seat cushion heater Wiring diagram
This page shows the only wiring diagram for the component.left front seat cushion heater, which is found in the car Ford Thunderbird XI (2000-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front seat cushion heater (1 of 1)
BATTERY JUNCTION BOX (BJB) (IN LUGGAGE COMPT, NEAR BATTERY)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN/RED WIRE
BRN/YEL WIRE
DRIVER SIDE FRONT HEATED SEAT MODULE (UNDER DRIVER SEAT)
DRIVER SIDE SEAT HEATER SWITCH
FUSE 10
FUSE 11
FUSE 16
GRY WIRE
GRY/ORG WIRE
HIGH IND OFF
HIGH OFF
HOT AT ALL TIMES
HOT IN RUN CENTRAL JUNCTION BOX (CJB) (BEHIND RIGHT KICK PANEL)
ILLUMINATION
LEFT FRONT SEAT BACK HEATER
LEFT FRONT SEAT CUSHION HEATER
LOW IND
OFF
PASSENGER SIDE FRONT HEATED SEAT MODULE (UNDER PASSENGER SEAT)
PASSENGER SIDE SEAT HEATER SWITCH
PNK WIRE
PNK/BLK WIRE
PNK/YEL WIRE
RED WIRE
RIGHT FRONT SEAT BACK HEATER
RIGHT FRONT SEAT CUSHION HEATER
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
YEL/GRN WIRE
Go to component: -> Heated seats circuit -> LEFT FRONT SEAT CUSHION HEATER
