Ford Thunderbird XI (2000-2005) central junction Wiring diagram
This page shows the only wiring diagram for the component.central junction, which is found in the car Ford Thunderbird XI (2000-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram central junction (1 of 1)
1 11 VPWR VPWR
15 16 SCP+ SCP-
7 1 SCP + SCP -
BATTERY JUNCTION
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BOX (BEHIND RIGHT KICK PANEL)
BOX (IN LUGGAGE COMPT, NEAR BATTERY)
BRN/YEL WIRE
CENTRAL JUNCTION
COMPUTER DATA LINES SYSTEM
CONVERTIBLE TOP SWITCH
COURTESY
DIMMER 3 2
DRIVER SIDE DOOR LOCK SWITCH
DRIVER SIDE SEAT HEATER SWITCH PASSENGER SIDE SEAT HEATER SWITCH
FRONT ELECTRONIC MODULE (IN LEFT ``A" PILLAR)
FUSE 1
FUSE 33
GRN WIRE
GRY WIRE
GRY/VIO WIRE
GRY/WHT WIRE
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMING MODULE (BEHIND LEFT SIDE OF DASH)
INTERIOR AUXILIARY JUNCTION BOX (UNDER LEFT SIDE OF DASH)
MAIN LIGHT SWITCH
MASTER WINDOW ADJUST SWITCH ELECTRONIC HIDDEN ANTENNA MODULE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
ORG/YEL WIRE
PASSENGER SIDE DOOR LOCK SWITCH
PASSENGER SIDE WINDOW ADJUST SWITCH
POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
PWR
RED WIRE
RELAY ENERGIZED
SCP+
SPEED CONTROL SWITCH
STEERING WHEEL AUXILIARY AUDIO CONTROLS
TRACTION CONTROL SWITCH
TRANSMISSION SHIFT SELECTOR
VIO WIRE
VPWR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/RED WIRE
Go to component: -> Instrument illumination circuit -> CENTRAL JUNCTION
